Chapter 8
Special Menu
8–10
When you press the
F1
soft designator key the Download
display shown in Figure 8.17 will appear.
Figure 8.17
Parameter File Download
Data
(25%)
Param Dnload:
– Xmt Par#: 130
I I I
I I I
0 50 100
A bar chart will scroll across the bottom of the Data Display to indicate the
percentage of the parameter table that is downloaded.
To cancel a download press the
F4
soft designator.
