Chapter 2
Parameter Option
2–8
When you selected your File option, the cursors automatically moved to the
Group window on the right side of the Display.
Use the or keys to scroll to your desired Group
selection.
Press the key to access the elements for this group (Figure 2.14).
Press
ESC
to return to the Group menu.
Figure 2.14
Element Selection
Val_Bas
F - Communication IO
Lin_Mode
F1 F2 F4 F3
An Out 1 Scale
An Out 1 Offset
< Analog Out 1>
Elem
G - Analog Output
Value : 0
Min : -32767
Max: +32767
Link: None
The first element under the Analog Output Group, Analog Output 1, is
shown within the cursors in Figure 2.15. To access the other elements in the
group, use the or keys to scroll thru the list.
To change values for this element, press the key to move to the
value field on the right side of the display (Fig. 2.15).
Group Selection
Element Selection
