Page 30: Ee/bram functions

Text mode
Original mode

Chapter

4–1

EE/BRAM Functions

The EE/BRAM Menu allows you to perform all non-volatile parameter
storage functions. You can save parameter changes to the Battery RAM on
the Adapter Board, save any process display changes you have made, or reset
the parameter table to initial values using this menu.

A help text box will appear with each menu option describing the selected
options.

From the Main Menu, use the

key to place the

cursor on Option 5, EEPROM/BRAM (Figure 4.1).

Figure 4.1

Main Menu

Main Menu:

3 - Fault Queue

4 - Warning Queue

< 5 - EEPROM/BRAM >

6 - Clock Data

7 - Function Block

Help

Press the

key to access the EE/BRAM menu (Figure 4.2).

Figure 4.2

EE/BRAM Menu

EE/BRAM Menu:

1 - Save Par to EE

2 - Recall EE Par

3 - Init. Par to RAM

Help

General

Accessing the EE/BRAM Function
