Chapter 8
Special Menu
8–5
From the Special Menu use the or key to select
option six (6) Drive Identity. Press the key and the Drive
Identity display in Figure 8.7 will appear.
Figure 8.7
Drive Identity Display
Drive Identity
Data
Name:
$
--(Char#)--
Char_#
! I # $ % & ( ) * +, - . /
0 1 2 3 4 5 6 7 8 9 : ; < = > ?
@ A B C D E F G H I J K L M N O
P Q R S T U V W X Y Z [ \ ]
∧
_
\ a b c d e f g h i j k l m n o
p q r s t u v w x y z ( ! ) ~
Char_Val
To enter a name of up to sixteen characters activate the character # selection
by pressing the
F1
soft designator key. The dialog box shown in
Figure 8.8 will appear.
Figure 8.8
Character Entry Box
Enter Character #:
< >
Min: 1 Max: 16
Changing Drive Identity
