Chapter 7
Process Display
7–5
If you have removed or disabled one Process Display variable and wish to
recall it from the drive, place the cursors on the selected Process Display
location with the or key. Press the
F3
soft designator and the parameter will be restored to the
Process Variable list.
With the Process Configuration Display called up, select the variable you
wish to change by placing the cursors on the variable with the or
key. Press the
F1
soft key to call up the
Configuration Programming Screen (Figure 7.7).
Figure 7.7
Configuration Program Display
Computed Power
Min: 1
Max: 497
Data
Parameter:
<
182
>
Scale: +1.0
Text: Computed
View
0.00 Computed
Config: Var #3
Changing Parameter Numbers: If you wish to change the parameter
number, place the cursors on the Data Parameter option using the
or key. Use the and keys
to change Variable #3 to the desired Parameter Number. Or you can directly
enter a parameter number using the numeric keys.
Changing the Scaling Factor: Use the or key to
place the cursors on the Data Scale option. Use the or
keys to change the Scaling Factor (Figure 7.8 ) or enter the
desired scaling factor directly with the numeric keys.
Recalling a Process Display
Variable
Programming a Configurable
Variable
