Rockwell Automation 1201 GRAPHIC PROGRAM TERM 3.XX User Manual
Page 51

Chapter 7
Process Display
7–6
Figure 7.8
Configuration Scaling Display
Min: -100.0
Max: +100.0
Data
Parameter:
182
Scale:
<
+1.0
>
Text: Computed
View
0.00 Computed
Config: Var #3
When the new scaling value is entered correctly, press the
ESC
key
to save the value and return to the Main Configuration window.
Changing the Configuration Text:
Place the cursors (< >) on the Text variable using the
or
key. Continue to use the
or
keys to
place the character selection cursor ($ sign) under the character you wish to
change (Figure 7.9).
Figure 7.9
Text Configuration Display
Data
Parameter: 182
Scale: +1.05
Text:
<
Computed
>
$
Min: 20
Max: 7F
View
Char_Val
Blank
Use the
or
key to scroll through the alphabet and
replace the selected letter with new text. All Upper and Lower case letters
and some additional keyboard symbols are available. Once you have reached
