Overview Chapter 4 provides information to guide the user in
troubleshooting the 1336 REGEN Line Regeneration Package.
Included is a listing and description of the various faults that can
occur and their code numbers as they would appear on the HIM.
An additional section is included to document troubleshooting
from the 1336 REGEN Converter Control Board. (3) LEDs on the
Control Board provide status and fault information for the 1336
REGEN Line Regeneration Package.
Clearing a Fault
When a fault occurs, the Enable & Fault Output Relays will
change state and the 1336 REGEN Converter will shut down. Issu-
ing a reset command will clear the fault and reset the converter.
When a fault occurs however, the cause should be investigated and
action taken prior to resetting the fault.
Troubleshooting 1336 REGEN Converter Control Board LED Indication
LED Status Indicates
Off No Faults Exist
On A Fault Has Occurred — Refer to the Fault Codes Below
Off No Power Has Been Applied to the Converter
On The Converter Is Being Powered Up
On Flashing The Converter Has Tripped — Refer to the Fault Codes Below
Off The Converter Is Not Enabled
On The Converter Is Enabled
On Flashing The Converter Has Tripped — Refer to the Fault Codes Below
Off The Converter Is Not Enabled
On
2 Flashes
A host checksum has occurred.
On
Continuous
Flashing
The Converter Has Tripped — Refer to the Fault Codes Below
DS1
FAULT
DS2
ENABLE
DS3
STATUS
DS4
COM
