Regenerative DC Bus Supply Operation 2–13
120VAC Precharge and
Converter Wiring 120VAC Converter Connections
120VAC input and output power connections are made to D
Frame Converters as shown below.
Figure 2.10 — 120VAC D Frame Converter Connections
DANGER
DANGER
S2
TORQUE TERM. TO 6 N-m (52 lb-in)
T2
USE 75 ° C COPPER WIRE ONLY
R2 DC- DC+
TE PE PE 120 RT N 120 VA C
! DANGER
ELECTRICAL SHOCK HAZARD FROM
ENERGY STORAGE CAPACITORS
VERIFY LOW VOLTAGE DISCHARGE
BEFORE SERVICING.
SEE INSTRUCTION MANUAL.
! DANGER
RISK OF SHOCK
REPLACE AFTER
SERVICING
! DANGER
RISK OF SHOCK
REPLACE AFTER
SERVICING
CAT 1336R-VB180CNV-AN-HAP SER A
119-150 AC INPUT K V A VOLTS A PH HZ AC OUTPUT DC OUTPUT REFER TO USER MANUAL FOR
INSTALLATION INSTRUCTIONS
180.4 – – – – – 3 50/60 380-480 144 196 – – 735 ALLEN-BRADLEY AB MADE IN U.S.A.
UL ® LIST ED 966X
IN D C O N T E Q UL ® LIST ED 966X
IN D C O N T E Q C
®
S2
TORQUE TERM. TO 6 N-m (52 lb-in)
T2
USE 75 ° C COPPER WIRE ONLY
R2 DC– DC+
TE PE PE 120 RT
N
120 VA
C
120 RTN
(120V
AC COMMON)
120V AC
(120V AC)
➊ ➊
t o p p e d S . 0 0 H z 0 +
➊ (2) jumpers connect PE and TE at the 1336 REGEN Converter Main Terminal Block.
Consult Allen-Bradley Application Engineering prior to removing either jumper.
D Frame
Converter
