3–34 Regenerative Brake Operation
Programming
Parameter No. 1
Display Units bits
Parameter Type Read/Write
Factory Default XXXXX000
Regen Brake Mode
Min/Max Value N/A
Drive Units 000 = 0
bin
Operational Mode
Sets the 1336 REGEN Line Regeneration Package mode of operation. The modes are defined
by the last (3) bits of a 16 bit word. To set the mode, first stop the 1336 REGEN Converter, set
the mode, then re-enable the converter.
Important: If the [Operational Mode] is reset while the 1336 REGEN Converter is enabled,
a System Mode Change Fault will occur. Issuing a reset command will clear the
fault and reset the converter.
Parameter No. 2
Display Units Amps
Parameter Type Read Onl y
Drive Units 1 = 0.1A
Rated AC Line Current
Displays the rated AC line current of the 1336 REGEN Converter.
Parameter No. 3
Display Units %
Min/Max Value -200/200
Parameter Type Read Only
Drive Units 100 = 4096
AC Line Current
Displays the actual I
q
AC line current in percent of rated AC line current. Positive values
indicate motoring — Negative values indicate regeneration.
Parameter No. 4
Display Units %
Min/Max Value -200/200
Parameter Type Read Only
Drive Units 100 = 4096
Peak Load
Displays the peak motoring or regenerating current in percent of rated AC current. The peak
value is held for five seconds. Positive values indicate motoring — Negative values indicate
regenerating.
i o n a l M o d e t p e r a O
0 0 1 0 X X X 0 X
Bit 2 Bit 1 Bit 0
0 = Regen Brake Mode 1 = Regen DC Bus Supply Mode
0 = Fixed DC Bus Mode 1 = DC Bus Trim Mode
0 = 460VAC Input Line Voltage 1 = 380VAC Input Line Voltage
0 = Fixed DC Bus 1 = Scheduled DC Bus
0 = Voltage Gain 1 = Voltage Gain
Bit 3
C u r r e n t a t e d R
0 A M P S 2 . 0 0
u r r e n t C i n e L
1 0 0 % 3 +
o a d L e a k P
1 0 0 % 4 +
