1321 180a 10% line reactor – Rockwell Automation 1336R REGEN LINE REG User Manual
Page 107

Dimensions and Weights
A–9
1321 180A 10% Line
Reactor
Important: Allow 152.4 mm (6.0 In.) on all sides for proper heat dissipation.
Mounting Hole Dia.
(4) Places
14.22
(0.56)
11.18 x 17.53
(0.44 x 0.69 Slot)
Shipping
Weight
136
(300)
61.2/160
(135/353)
1321 Rating
180A Open (IP00)
78A/180A
NEMA Type 1 (IP20)
All Dimensions in Millimeters and (Inches) — All Weights in Kilograms and (Pounds)
A
304.8
(12.00)
—
B
292.4
(11.51)
609.6
(24.00)
C
368.3
(14.50)
—
D
116.8
(4.60)
434.9
(17.12)
E
94.0
(3.70)
—
F
184.2
(7.25)
—
G
254.3
(10.01)
—
H
—
432
(17.0)
I
317.5
(12.50)
467
(18.38)
TOP
C
SIDE
I
END
TOP
Dia.
D
A
F
E
E
G
B
Dia.
R
2
S
2
T
2
T
1
S
1
R
1
L
T2
T1
Manufactured By MTE Corp.
Menomonee Falls, WI
I
Wt
Type
Rise
Part#
CAT 1321-3LRA180-B
Hz
Class
VAC
R2
R1
S2
S1
INDUSTRIAL CONTROL EQUIPMENT
UL
®
LIST
ED 966X
IN D
C O N T E
Q
UL
®
LIST
ED 966X
IN D
C O N T E
Q
C
3 Phase Reactors 9730
Listed
34HL
0.430mH
180AMPS
60
460
353 lbs.
1
115ºC
H
I
SIDE
D
Dia.
– 4 Places –
R
2
S
2
T
2
T
1
S
1
R
1
COVER
END
H
B
Manufactured By MTE Corp.
Menomonee Falls, WI
T2
T1
R2
R1
S2
S1
RL-18004
CAT 1321-3LR180-B
PART#
0.430mH 180AMPS
lth-270A 9730
E66214 180-36
3 PHASE REACTOR
600V MAX 50/60 Hz
®
®
®
C
