Chopper module characteristics – Rockwell Automation 1336_F_E_T_S SERIES A CHOPPER BRAKE MODULE User Manual
Page 20
Heavy Duty Dynamic Braking
20
1336-5.65 — March, 2007
Chopper Module
Characteristics
Drive Voltage
(Volts AC)
Turn-On Voltage
(Volts DC)
Catalog Number
Chopper Peak Transistor
Current Rating (Amps)
Minimum Dynamic Brake
Resistance Value (Ohms)
230
375
WA115
400
1.25
WA070
200
2.3
WA018
50
9.0
460
750
WB110
400
2.5
WB035
100
9.0
WB009
25
37.0
575
935
WC085
400
3.0
WC035
75
15.5
WC009
25
46.0
