Heavy Duty Dynamic Braking 19
1336-5.65 — March, 2007
5.1 59486 PF5F1R59K4 7375900 Powerohm
5.1 114750 PF5F1R114K4 25239300 Powerohm
5 22848 442-18A 1603773 IPC
5 30978 552-20A 1651395 IPC
5 34269 442-18 959801 IPC
5 46464 552-20 3891643 IPC
5 51028 445-18A 1733701 IPC
5 76534 445-18 3651418 IPC
4.8 2580 T4F8R2K58 185000 IPC
4.8 4590 T4F8R4K59 401000 IPC
4.8 5490 T4F8R5K49 169000 IPC
4.8 8880 T4F8R8K88 260000 IPC
4.8 10900 T4F8R10K9 359000 IPC
4.8 19200 T4F8R19K2 586000 IPC
4.8 25800 T4F8R25K8 984000 IPC
4.8 34600 T4F8R34K6 2310000 IPC
4.8 58200 T4F8R58K2 3696000 IPC
4.8 61000 T4F8R61K0 3916000 IPC
4.8 99300 T4F8R99K3 6159000 IPC
4.8 132000 T4F8R132K0 8077000 IPC
4.6 400 PF4F6R400W 16200 Powerohm
4.6 800 PF4F6R800W 37800 Powerohm
4.6 1200 PF4F6R1K20 53900 Powerohm
4.6 1600 PF4F6R1K60 125900 Powerohm
4.6 1630 PF4F6R1K62 61800 Powerohm
4.6 1801 PF4F6R1K80 71700 Powerohm
4.6 2433 PF4F6R2K43 133100 Powerohm
4.6 3120 PF4F6R3K12 168500 Powerohm
4.6 3869 PF4F6R3K86 383500 Powerohm
4.6 4710 PF4F6R4K71 537700 Powerohm
4.6 7360 PF4F6R7K36 1412200 Powerohm
4.6 9733 PF4F6R9K73 564200 Powerohm
4.6 12438 PF4F6R12K4 683600 Powerohm
4.6 15600 PF4F6R15K6 1497400 Powerohm
4.6 18841 PF4F6R18K8 2028400 Powerohm
4.6 23846 PF4F6R23K8 3073300 Powerohm
4.6 34817 PF4F6R34K8 3495100 Powerohm
4.6 66240 PF4F6R66K2 11386500 Powerohm
4.6 149040 PF4F6R149K9 37346900 Powerohm
4.5 6184 222-12A 152850 IPC
4.5 8266 222-12 239950 IPC
4.5 13810 225-12A 660558 IPC
4.5 20612 220-12A 1425576 IPC
4.5 20715 225-12 1425576 IPC
4.5 30918 220-12 1486256 IPC
4 28207 442-19A 1321116 IPC
4 42308 442-19 1386961 IPC
4 44057 552-21A 3441020 IPC
4 66084 552-21 1799627 IPC
3.9 32736 442-20A 2405659 IPC
3.9 49108 442-20 3246136 IPC
3.9 62996 445-19A 8013142 IPC
3.8 7227 222-13A 182571 IPC
3.8 9788 222-13 328491 IPC
3.8 16139 225-13A 430346 IPC
3.8 24089 220-13A 751149 IPC
Ohms Watts Catalog
Watt
Seconds
Manufacturer
3.8 24212 225-13 1321116 IPC
3.8 36138 220-13 2672955 IPC
3.3 1200 PF3F3R1K20 61000 Powerohm
3.3 1876 PF3F3R1K87 105500 Powerohm
3.3 2230 PF3F3R2K23 124600 Powerohm
3.3 2775 PF3F3R2K77 317800 Powerohm
3.3 3379 PF3F3R3K37 380400 Powerohm
3.3 4299 PF3F3R4K29 556400 Powerohm
3.3 6982 PF3F3R6K98 376100 Powerohm
3.3 9251 PF3F3R9K25 512700 Powerohm
3.3 11101 PF3F3R11K1 1197900 Powerohm
3.3 13516 PF3F3R13K5 1530100 Powerohm
3.3 21489 PF3F3R21K4 3595800 Powerohm
3.3 24977 PF3F3R24K9 2541900 Powerohm
3.3 38491 PF3F3R38K4 5071000 Powerohm
3.3 47520 PF3F3R47K5 8390100 Powerohm
3.3 75001 PF3F3R75K0 15984900 Powerohm
3.3 106920 PF3F3R106K6 26362500 Powerohm
3.3 150001 PF3F3R150K0 41191400 Powerohm
3.3 214582 PF3F3R214K4 70836500 Powerohm
2.7 10500 222-14A 521631 IPC
2.7 15750 222-14 520110 IPC
2.7 23452 225-14A 1173670 IPC
2.7 35003 220-14A 2164091 IPC
2.7 35178 225-14 2187360 IPC
2.6 44505 442-21A 1126723 IPC
2.3 800 PF2F3R800W 63000 Powerohm
2.3 1200 PF2F3R1K20 56900 Powerohm
2.3 1600 PF2F3R1K60 165200 Powerohm
2.3 1664 PF2F3R1K66 112400 Powerohm
2.3 1934 PF2F3R1K93 211900 Powerohm
2.3 2356 PF2F3R2K35 253600 Powerohm
2.3 2980 PF2F3R2K98 365700 Powerohm
2.3 3680 PF2F3R3K68 723300 Powerohm
2.3 7737 PF2F3R7K73 767000 Powerohm
2.3 9420 PF2F3R9K42 1075400 Powerohm
2.3 14720 PF2F3R14K7 2824300 Powerohm
2.3 17408 PF2F3R17K4 1588700 Powerohm
2.3 27501 PF2F3R27K5 3688000 Powerohm
2.3 33273 PF2F3R33K2 5992900 Powerohm
2.3 55001 PF2F3R55K0 11778400 Powerohm
2.3 74520 PF2F3R74K5 18673500 Powerohm
2.2 13370 222-15A 316618 IPC
2.2 20053 222-15 1603773 IPC
2.2 29860 225-15A 1685270 IPC
2.2 44785 225-15 1724576 IPC
2.1 1200 PF2F1R1K20 84900 Powerohm
2.1 1420 PF2F1R1K42 83100 Powerohm
2.1 1767 PF2F1R1K76 168000 Powerohm
2.1 2151 PF2F1R2K15 253600 Powerohm
2.1 2722 PF2F1R2K72 365700 Powerohm
2.1 3361 PF2F1R3K36 599300 Powerohm
2.1 4443 PF2F1R4K44 266100 Powerohm
1.88 15350 222-16A 782447 IPC
1.88 23026 222-16 1570711 IPC
1.88 34281 225-16A 2138364 IPC
1.5 19884 222-17A 1308926 IPC
Ohms Watts Catalog
Watt
Seconds
Manufacturer
