Heavy Duty Dynamic Braking 17
1336-5.65 — March, 2007
20 600 T20R600W 17300 IPC
20 900 T20R900W 18500 IPC
20 1372 222-7A 87086 IPC
20 1500 T20R1K5 28000 IPC
20 1860 222-7 55084 IPC
20 3063 225-7A 138493 IPC
20 4572 220-7A 222215 IPC
20 4650 225-7 221432 IPC
20 5940 T20R5K94 260000 IPC
20 7031 220-7 169227 IPC
20 8920 T20R8K92 267000 IPC
20 10700 T20R10K7 582000 IPC
20 15200 T20R15K2 924000 IPC
20 16605 440-11A 825698 IPC
20 20600 T20R20K6 1602000 IPC
20 24910 440-11 1781970 IPC
20 28400 T20R28K4 1066000 IPC
20 34600 T20R34K6 1148000 IPC
19 400 PF19R400W 17100 Powerohm
19 800 PF19R800W 39000 Powerohm
19 1200 PF19R1K20 84900 Powerohm
19 1600 PF19R1K60 68300 Powerohm
19 2000 PF19R2K00 213200 Powerohm
19 2800 PF19R2K80 339300 Powerohm
19 3200 PF19R3K20 344700 Powerohm
19 4864 PF19R4K86 207300 Powerohm
19 6716 PF19R6K71 220000 Powerohm
19 8213 PF19R8K21 272600 Powerohm
19 9540 552-14A 410613 IPC
19 10051 PF19R10K0 564200 Powerohm
19 12170 552-14 410613 IPC
19 13613 PF19R13K6 700700 Powerohm
19 16425 PF19R16K4 1497400 Powerohm
19 19456 PF19R19K4 2155200 Powerohm
19 21305 555-14A 1514674 IPC
19 30400 PF19R30K4 5393600 Powerohm
19 31798 550-14A 3029900 IPC
19 31965 555-14 2913365 IPC
19 40204 PF19R40K2 2128200 Powerohm
19 47709 550-14 5953399 IPC
19 63916 PF19R63K9 6142800 Powerohm
19 77824 PF19R77K8 8113500 Powerohm
18 6184 442-12A 152850 IPC
18 8266 442-12 234734 IPC
18 13810 445-12A 660558 IPC
18 20612 440-12A 1336477 IPC
18 20664 445-12 1336477 IPC
18 30910 440-12 899814 IPC
15.4 800 PF15F4R800W 42400 Powerohm
15.4 1200 PF15F4R1K20 106000 Powerohm
15.4 2400 PF15F4R2K40 123100 Powerohm
15.4 5063 PF15F4R5K06 165000 Powerohm
15.4 10410 PF15F4R10K4 600600 Powerohm
15.4 20251 PF15F4R20K2 2612300 Powerohm
15.4 41642 PF15F4R41K6 2407200 Powerohm
15 300 T15R300W 16400 IPC
15 600 T15R600W 20800 IPC
15 900 T15R900W 22000 IPC
15 1500 T15R1K5 38800 IPC
15 4210 T15R4K21 143000 IPC
15 6160 T15R6K16 232000 IPC
15 7132 442-13A 179963 IPC
15 8570 T15R8K57 466000 IPC
15 9919 442-13 328491 IPC
15 11400 T15R11K4 734000 IPC
15 12112 552-15A 550465 IPC
15 15927 445-13A 1158280 IPC
Ohms Watts Catalog
Watt
Seconds
Manufacturer
15 18173 552-15 1158280 IPC
15 23772 440-13A 719851 IPC
15 23894 445-13 719851 IPC
15 27060 555-15A 719851 IPC
15 35663 440-13 1313963 IPC
15 40388 550-15A 1300276 IPC
15 40587 555-15 1313963 IPC
15 60579 550-15 7591398 IPC
14 300 T14R300W 15400 IPC
14 600 T14R600W 19400 IPC
14 900 T14R900W 20700 IPC
14 1200 T14R1K2 24500 IPC
14 1800 T14R1K8 27800 IPC
14 2012 222-8A 61344 IPC
14 2657 222-8 154455 IPC
14 4495 225-8A 117367 IPC
14 6160 T14R6K16 232000 IPC
14 6642 225-8 172138 IPC
14 6708 220-8A 172138 IPC
14 10045 220-8 523728 IPC
14 11400 T14R11K4 734000 IPC
14 12700 T14R12K7 1038000 IPC
13 800 PF13R800W 58400 Powerohm
13 1600 PF13R1K60 111200 Powerohm
13 2800 PF13R2K80 238800 Powerohm
13 5457 PF13R5K45 191600 Powerohm
13 11000 PF13R11K0 1048200 Powerohm
12 9641 442-14A 440372 IPC
12 12398 442-14 890985 IPC
12 13780 552-16A 890985 IPC
12 20673 552-16 599876 IPC
12 21531 445-14A 1924486 IPC
12 30776 555-16A 1040221 IPC
12 32136 440-14A 1040221 IPC
12 32297 445-14 1040221 IPC
12 45934 550-16A 2387466 IPC
12 46170 555-16 2247026 IPC
12 48204 440-14 1314510 IPC
12 68911 550-16 10015318 IPC
11.5 400 PF11F5R400W 25700 Powerohm
11.5 800 PF11F5R800W 41300 Powerohm
11.5 1600 PF11F5R1K60 102600 Powerohm
11.5 2000 PF11F5R2K00 206500 Powerohm
11.5 2944 PF11F5R2K94 146900 Powerohm
11.5 3726 PF11F5R3K72 140900 Powerohm
11.5 4600 PF11F5R4K60 191600 Powerohm
11.5 6083 PF11F5R6K08 321100 Powerohm
11.5 7774 PF11F5R7K77 500500 Powerohm
11.5 9671 PF11F5R9K67 898500 Powerohm
11.5 11776 PF11F5R11K7 1254700 Powerohm
11.5 14904 PF11F5R14K9 1955300 Powerohm
11.5 18400 PF11F5R18K4 3196300 Powerohm
11.5 24334 PF11F5R24K3 1330100 Powerohm
11.5 31096 PF11F5R31K0 1840800 Powerohm
11.5 59616 PF11F5R59K6 7683200 Powerohm
11.5 110001 PF11F5R110K0 11663100 Powerohm
11 2561 222-9A 121123 IPC
11 3381 222-9 100080 IPC
11 5720 225-9A 237243 IPC
11 8454 225-9 407344 IPC
11 8537 220-9A 407344 IPC
11 12784 220-9 890985 IPC
10.4 300 T10F4R300W 17300 IPC
10.4 600 T10F4R600W 22900 IPC
10.4 900 T10F4R900W 24500 IPC
10.4 1500 T10F4R1K5 25400 IPC
10.4 2970 T10F4R2K97 95100 IPC
Ohms Watts Catalog
Watt
Seconds
Manufacturer
