Heavy Duty Dynamic Braking 13
1336-5.65 — March, 2007
Chopper Module Selection
Ohms Watts Catalog
Watt
Seconds
Manufacturer
956 242 552-1 4225 IPC
956 400 555-1A 6260 IPC
956 597 550-1A 6260 IPC
956 605 555-1 6260 IPC
956 915 550-1 6260 IPC
695 248 552-2A 4929 IPC
695 333 552-2 4929 IPC
695 553 555-2A 7981 IPC
695 825 550-2A 7981 IPC
695 832 555-2 7981 IPC
695 1258 550-2 15258 IPC
615 180 442-1A 4225 IPC
615 242 442-1 4225 IPC
615 404 445-1A 4225 IPC
615 602 440-1A 13302 IPC
615 605 445-1 13615 IPC
615 915 440-1 13302 IPC
546 316 552-3A 5634 IPC
546 424 552-3 12050 IPC
546 707 555-3A 12050 IPC
546 1055 550-3A 23004 IPC
546 1059 555-3 23004 IPC
546 1601 550-3 36619 IPC
439 254 442-2A 2973 IPC
439 339 442-2 2973 IPC
439 568 445-2A 2973 IPC
439 847 445-2 11267 IPC
439 848 440-2A 9389 IPC
439 1281 440-2 24647 IPC
364 477 552-4A 3990 IPC
364 635 552-4 15336 IPC
364 1065 555-4A 24412 IPC
364 1588 555-4 38496 IPC
364 1590 550-4A 38496 IPC
364 2402 550-4 39514 IPC
342 329 442-3A 3677 IPC
342 435 442-3 3677 IPC
342 734 445-3A 14397 IPC
342 1088 445-3 23473 IPC
342 1096 440-3A 22534 IPC
342 1645 440-3 36306 IPC
283 614 552-5A 19092 IPC
283 817 552-5 19092 IPC
283 1372 555-5A 30046 IPC
283 2043 555-5 48120 IPC
283 2048 550-5A 47338 IPC
283 3089 550-5 76680 IPC
237 473 442-4A 5321 IPC
237 628 442-4 15649 IPC
237 1057 445-4A 25351 IPC
237 1570 445-4 38496 IPC
237 1577 440-4A 39748 IPC
237 2373 440-4 61422 IPC
196 890 552-6A 20970 IPC
196 1180 552-6 33567 IPC
196 1987 555-6A 53519 IPC
196 2950 555-6 83096 IPC
196 2965 550-6A 83096 IPC
196 4460 550-6 130669 IPC
181 620 442-5A 19248 IPC
181 822 442-5 19248 IPC
181 1385 445-5A 30985 IPC
181 2055 445-5 77853 IPC
181 2068 440-5A 77853 IPC
181 3108 440-5 77775 IPC
154 182 222-1A 6416 IPC
154 242 222-1 6416 IPC
154 408 225-1A 6416 IPC
154 604 225-1 16431 IPC
154 610 220-1A 16431 IPC
154 913 220-1 16431 IPC
150 400 PF150R400W 7700 Powerohm
150 800 PF150R800W 12100 Powerohm
150 1200 PF150R1K20 30000 Powerohm
150 1600 PF150R1K60 54200 Powerohm
150 2000 PF150R2K00 53500 Powerohm
150 2400 PF150R2K40 82500 Powerohm
150 2800 PF150R2K80 132000 Powerohm
150 3200 PF150R3K20 136500 Powerohm
150 3600 PF150R3K60 196200 Powerohm
150 4000 PF150R4K00 192400 Powerohm
150 5200 PF150R5K20 333400 Powerohm
150 5600 PF150R5K60 329100 Powerohm
128 874 442-6A 22065 IPC
128 1162 442-6 32863 IPC
128 1951 445-6A 55397 IPC
128 2906 445-6 86382 IPC
128 2912 440-6A 82626 IPC
128 4395 440-6 138024 IPC
125 400 PF125R400W 6500 Powerohm
125 800 PF125R800W 18300 Powerohm
125 1200 PF125R1K20 25200 Powerohm
125 1386 552-7A 32863 IPC
125 1600 PF125R1K60 44200 Powerohm
125 1850 552-7 51954 IPC
125 2000 PF125R2K00 68700 Powerohm
125 3095 555-7A 130903 IPC
125 3600 PF125R3K60 161600 Powerohm
125 4000 PF125R4K00 277800 Powerohm
125 4620 550-7A 208131 IPC
125 4625 555-7 208131 IPC
125 6994 550-7 212513 IPC
125 7200 PF125R7K20 341300 Powerohm
125 7600 PF125R7K60 344600 Powerohm
117 300 T117R300W 7950 IPC
117 600 T117R600W 10100 IPC
117 900 T117R900W 10600 IPC
117 1200 T117R1K2 12500 IPC
117 1500 T117R1K5 15800 IPC
117 2100 T117R2K1 18600 IPC
117 2700 T117R2K7 14300 IPC
117 3000 T117R3K0 20800 IPC
110 255 222-2A 7511 IPC
110 338 222-2 7511 IPC
110 570 225-2A 18779 IPC
110 845 225-2 18779 IPC
110 850 220-2A 18779 IPC
110 1278 220-2 46947 IPC
100 400 PF100R400W 5200 Powerohm
100 800 PF100R800W 20000 Powerohm
100 1200 PF100R1K20 35300 Powerohm
100 1600 PF100R1K60 55000 Powerohm
100 2000 PF100R2K00 89800 Powerohm
100 2400 PF100R2K40 130800 Powerohm
100 2800 PF100R2K80 125700 Powerohm
100 3600 PF100R3K60 211600 Powerohm
100 4000 PF100R4K00 205200 Powerohm
100 4800 PF100R4K80 285500 Powerohm
100 5200 PF100R5K20 275000 Powerohm
100 5600 PF100R5K60 273100 Powerohm
