Heavy Duty Dynamic Braking 14
1336-5.65 — March, 2007
100 6800 PF100R6K80 450100 Powerohm
100 8000 PF100R8K00 692400 Powerohm
100 9200 PF100R9K20 676300 Powerohm
97 300 T97R300W 10300 IPC
97 600 T97R600W 13400 IPC
97 900 T97R900W 13800 IPC
97 1200 T97R1K2 16500 IPC
97 1500 T97R1K5 20800 IPC
97 2100 T97R2K1 15400 IPC
97 2700 T97R2K7 19100 IPC
97 3000 T97R3K0 16800 IPC
97 3600 T97R3K6 22400 IPC
97 4200 T97R4K2 19100 IPC
85 326 222-3A 9076 IPC
85 400 PF85R400W 6900 Powerohm
85 438 222-3 9076 IPC
85 730 225-3A 23004 IPC
85 800 PF85R800W 17200 Powerohm
85 1089 220-3A 36384 IPC
85 1094 225-3 36384 IPC
85 1200 PF85R1K20 46200 Powerohm
85 1600 PF85R1K60 75400 Powerohm
85 1654 220-3 57901 IPC
85 2000 PF85R2K00 109000 Powerohm
85 2056 552-8A 57588 IPC
85 2720 552-8 92016 IPC
85 2800 PF85R2K80 179500 Powerohm
85 3600 PF85R3K60 173600 Powerohm
85 4592 555-8A 233795 IPC
85 5200 PF85R5K20 379200 Powerohm
85 5600 PF85R5K60 383300 Powerohm
85 6800 PF85R6K80 588500 Powerohm
85 6801 555-8 231135 IPC
85 6854 550-8A 231135 IPC
85 7200 PF85R7K20 578500 Powerohm
85 10000 PF85R10K0 934100 Powerohm
85 10285 550-8 361490 IPC
85 11200 PF85R11K2 923100 Powerohm
81 1389 442-7A 34975 IPC
81 1837 442-7 55084 IPC
81 3102 445-7A 55319 IPC
81 4592 445-7 224640 IPC
81 4629 440-7A 221432 IPC
81 6944 440-7 221276 IPC
80 300 T80R300W 8530 IPC
80 400 PF80R400W 6500 Powerohm
80 600 T80R600W 10900 IPC
80 800 PF80R800W 16000 Powerohm
80 900 T80R900W 18500 IPC
80 1200 T80R1K2 13700 IPC
80 1200 PF80R1K20 44600 Powerohm
80 1500 T80R1K5 17500 IPC
80 2000 PF80R2K00 102600 Powerohm
80 2100 T80R2K1 19100 IPC
80 2700 T80R2K7 24600 IPC
80 3000 T80R3K0 22100 IPC
80 3600 T80R3K6 18500 IPC
80 4000 PF80R4K00 229300 Powerohm
80 4200 T80R4K2 25100 IPC
80 4500 T80R4K5 23300 IPC
80 5700 T80R5K7 29400 IPC
80 7600 PF80R7K60 545700 Powerohm
80 8000 PF80R8K00 897500 Powerohm
80 9000 T80R9K0 209000 IPC
80 9300 T80R9K3 230000 IPC
77 300 T77R300W 8210 IPC
77 600 T77R600W 10600 IPC
Ohms Watts Catalog
Watt
Seconds
Manufacturer
77 900 T77R900W 17900 IPC
77 1200 T77R1K2 20800 IPC
77 1500 T77R1K5 16400 IPC
77 2100 T77R2K1 19100 IPC
77 2700 T77R2K7 23800 IPC
77 3000 T77R3K0 21300 IPC
77 3600 T77R3K6 28100 IPC
77 4200 T77R4K2 24200 IPC
77 4500 T77R4K5 22400 IPC
77 5700 T77R5K7 28700 IPC
77 9000 T77R9K0 209000 IPC
77 9300 T77R9K3 230000 IPC
70 400 PF70R400W 5700 Powerohm
70 800 PF70R800W 25000 Powerohm
70 1200 PF70R1K20 62000 Powerohm
70 2400 PF70R2K40 153900 Powerohm
70 2527 552-9A 76680 IPC
70 3303 552-9 144048 IPC
70 4800 PF70R4K80 308300 Powerohm
70 5643 555-9A 189665 IPC
70 8258 555-9 297173 IPC
70 8424 550-9A 295765 IPC
70 9600 PF70R9K60 1249300 Powerohm
70 12489 550-9 482144 IPC
65 400 PF65R400W 9500 Powerohm
65 800 PF65R800W 23600 Powerohm
65 1200 PF65R1K20 59300 Powerohm
65 2000 PF65R2K00 138900 Powerohm
65 2400 PF65R2K40 141100 Powerohm
65 3600 PF65R3K60 178100 Powerohm
65 4000 PF65R4K00 291700 Powerohm
65 7200 PF65R7K20 712100 Powerohm
65 7600 PF65R7K60 709900 Powerohm
65 16640 PF65R16K6 690800 Powerohm
60 300 T60R300W 10300 IPC
60 400 PF60R400W 8700 Powerohm
60 600 T60R600W 13000 IPC
60 800 PF60R800W 21400 Powerohm
60 900 T60R900W 13700 IPC
60 1200 T60R1K2 16400 IPC
60 1500 T60R1K5 20800 IPC
60 2000 PF60R2K00 128300 Powerohm
60 2700 T60R2K7 18500 IPC
60 3600 T60R3K6 22000 IPC
60 4000 PF60R4K00 269300 Powerohm
60 4500 T60R4K5 28000 IPC
60 6900 T60R6K9 164000 IPC
60 8000 PF60R8K00 659400 Powerohm
60 11000 T60R11K0 448000 IPC
60 15896 PF60R15K8 690800 Powerohm
59 473 222-4A 10094 IPC
59 631 222-4 25038 IPC
59 1056 225-4A 39201 IPC
59 1576 225-4 64161 IPC
59 1577 220-4A 64161 IPC
59 2384 220-4 99762 IPC
56 2010 442-8A 61344 IPC
56 2657 442-8 154455 IPC
56 4490 445-8A 245062 IPC
56 6642 445-8 245375 IPC
56 6702 440-8A 245375 IPC
56 10045 440-8 388094 IPC
55 400 PF55R400W 8000 Powerohm
55 800 PF55R800W 30800 Powerohm
52 400 PF52R400W 10400 Powerohm
52 800 PF52R800W 28600 Powerohm
52 1200 PF52R1K20 65400 Powerohm
Ohms Watts Catalog
Watt
Seconds
Manufacturer
