Heavy Duty Dynamic Braking 15
1336-5.65 — March, 2007
52 1600 PF52R1K60 111200 Powerohm
52 2400 PF52R2K40 149600 Powerohm
52 2800 PF52R2K80 142400 Powerohm
52 3200 PF52R3K20 233400 Powerohm
52 4800 PF52R4K80 352900 Powerohm
52 5600 PF52R5K60 569300 Powerohm
52 6000 PF52R6K00 577000 Powerohm
52 9600 PF52R9K60 598400 Powerohm
52 13312 PF52R13K3 621800 Powerohm
52 18625 PF52R18K6 583500 Powerohm
48 300 T48R300W 13100 IPC
48 400 PF48R400W 9600 Powerohm
48 600 T48R600W 16500 IPC
48 800 PF48R800W 26400 Powerohm
48 900 T48R900W 17500 IPC
48 1200 T48R1K2 20800 IPC
48 1200 PF48R1K20 61600 Powerohm
48 1500 T48R1K5 16600 IPC
48 2000 PF48R2K00 98500 Powerohm
48 2700 T48R2K7 23300 IPC
48 3000 T48R3K0 21100 IPC
48 3600 T48R3K6 28000 IPC
48 3600 PF48R3K60 86200 Powerohm
48 4200 T48R4K2 23800 IPC
48 5670 T48R5K67 131000 IPC
48 6600 T48R6K6 131000 IPC
48 12600 T48R12K6 359000 IPC
48 19100 T48R19K1 656000 IPC
48 20400 T48R20K4 716000 IPC
45 300 T45R300W 12300 IPC
45 600 T45R600W 15800 IPC
45 617 222-5A 30828 IPC
45 827 222-5 30828 IPC
45 1200 T45R1K2 19100 IPC
45 1378 225-5A 49529 IPC
45 1500 T45R1K5 24900 IPC
45 2056 220-5A 124800 IPC
45 2066 225-5 124800 IPC
45 2100 T45R2K1 28100 IPC
45 2700 T45R2K7 22000 IPC
45 3000 T45R3K0 19800 IPC
45 3125 220-5 197177 IPC
45 3600 T45R3K6 26600 IPC
45 3883 552-10A 120810 IPC
45 5138 552-10 308128 IPC
45 6000 T45R6K0 125000 IPC
45 8672 555-10A 370410 IPC
45 12600 T45R12K6 359000 IPC
45 12846 555-10 409420 IPC
45 12943 550-10A 409420 IPC
45 19100 T45R19K1 656000 IPC
45 19427 550-10 563362 IPC
44 400 PF44R400W 8800 Powerohm
44 800 PF44R800W 39500 Powerohm
44 1200 PF44R1K20 57700 Powerohm
44 2000 PF44R2K00 126100 Powerohm
44 2561 442-9A 121670 IPC
44 2800 PF44R2K80 197900 Powerohm
44 3381 442-9 190604 IPC
44 3600 PF44R3K60 79000 Powerohm
44 4000 PF44R4K00 300900 Powerohm
44 5600 PF44R5K60 477000 Powerohm
44 5720 445-9A 184031 IPC
44 7200 PF44R7K20 793400 Powerohm
44 7600 PF44R7K60 775400 Powerohm
44 8454 445-9 305624 IPC
44 8537 440-9A 302807 IPC
Ohms Watts Catalog
Watt
Seconds
Manufacturer
44 11264 PF44R11K2 483600 Powerohm
44 12784 440-9 369388 IPC
44 15000 PF44R15K0 495000 Powerohm
44 23276 PF44R23K2 1263600 Powerohm
40 300 T40R300W 10900 IPC
40 400 PF40R400W 8000 Powerohm
40 800 PF40R800W 35900 Powerohm
40 900 T40R900W 14300 IPC
40 1200 T40R1K2 17300 IPC
40 1200 PF40R1K20 83400 Powerohm
40 1800 T40R1K8 18500 IPC
40 2000 PF40R2K00 114700 Powerohm
40 3200 PF40R3K20 277000 Powerohm
40 4000 T40R4K0 105000 IPC
40 4000 PF40R4K00 448800 Powerohm
40 6000 PF40R6K00 727000 Powerohm
40 10000 T40R10K0 309000 IPC
40 10240 PF40R10K2 414500 Powerohm
40 11000 T40R11K0 333000 IPC
40 11429 PF40R11K4 440000 Powerohm
40 16000 T40R16K0 521000 IPC
40 16000 PF40R16K0 638700 Powerohm
40 17000 T40R17K0 574000 IPC
40 19000 T40R19K0 568000 IPC
40 22000 T40R22K0 1202000 IPC
40 22858 PF40R22K8 1130600 Powerohm
36 400 PF36R400W 12900 Powerohm
36 800 PF36R800W 32400 Powerohm
36 1200 PF36R1K20 77000 Powerohm
36 1600 PF36R1K60 103200 Powerohm
36 2000 PF36R2K00 99000 Powerohm
36 2400 PF36R2K40 79200 Powerohm
36 4000 PF36R4K00 395700 Powerohm
36 4400 PF36R4K40 399000 Powerohm
36 9216 PF36R9K21 414500 Powerohm
36 11298 555-11A 316618 IPC
36 16517 555-11 449907 IPC
36 16863 550-11A 449907 IPC
36 19044 PF36R19K0 1064100 Powerohm
36 24978 550-11 1321116 IPC
35 5058 552-11A 157272 IPC
35 6423 552-11 249757 IPC
34 300 T34R300W 14700 IPC
34 900 T34R900W 19100 IPC
34 1800 T34R1K8 25100 IPC
34 2400 T34R2K4 30100 IPC
34 3600 T34R3K6 93000 IPC
34 4000 T34R4K0 98600 IPC
34 8000 T34R8K0 262000 IPC
34 9000 T34R9K0 285000 IPC
34 13000 T34R13K0 456000 IPC
34 15000 T34R15K0 456000 IPC
34 17000 T34R17K0 990000 IPC
34 18000 T34R18K0 1017000 IPC
34 19000 T34R19K0 1048000 IPC
34 26000 T34R26K0 1591000 IPC
32 300 T32R300W 13800 IPC
32 400 PF32R400W 11400 Powerohm
32 600 T32R600W 17500 IPC
32 800 PF32R800W 41100 Powerohm
32 875 222-6A 35054 IPC
32 900 T32R900W 19100 IPC
32 1162 222-6 55162 IPC
32 1200 PF32R1K20 70600 Powerohm
32 1500 T32R1K5 28100 IPC
32 1600 PF32R1K60 91800 Powerohm
32 1955 225-6A 88573 IPC
Ohms Watts Catalog
Watt
Seconds
Manufacturer
