Rockwell Automation 1336_F_E_T_S SERIES A CHOPPER BRAKE MODULE - Manual (Page 18)

Heavy Duty Dynamic Braking 18
1336-5.65 — March, 2007
10.4 5360 T10F4R5K36 329000 IPC
10.4 6040 T10F4R6K4 489000 IPC
10.4 8890 T10F4R8K89 801000 IPC
10.4 11000 T10F4R11K0 359000 IPC
10.4 15500 T10F4R15K5 1742000 IPC
10.4 18900 T10F4R18K9 1991000 IPC
10.4 26000 T10F4R26K0 2002000 IPC
10.4 35600 T10F4R35K6 1230000 IPC
10.4 43900 T10F4R43K9 1367000 IPC
10.4 72300 T10F4R72K3 4620000 IPC
10.1 400 PF10F1R400W 20600 Powerohm
10.1 800 PF10F1R800W 35900 Powerohm
10.1 1200 PF10F1R1K20 112100 Powerohm
10 17713 552-17A 479901 IPC
10 26569 552-17 903350 IPC
10 39559 555-17A 1956117 IPC
10 59043 550-17A 1950414 IPC
10 59339 555-17 1950414 IPC
9.5 11926 442-15A 316618 IPC
9.5 17890 442-15 479901 IPC
9.5 26636 445-15A 3000513 IPC
9.5 39755 440-15A 2851152 IPC
9.5 39955 445-15 1079776 IPC
9.5 59635 440-15 1820386 IPC
9.2 400 PF9F2R400W 18900 Powerohm
9.2 800 PF9F2R800W 32400 Powerohm
9.2 1200 PF9F2R1K20 102200 Powerohm
9.2 1600 PF9F2R1K60 75500 Powerohm
9.2 2000 PF9F2R2K00 161600 Powerohm
9.2 2355 PF9F2R2K35 98000 Powerohm
9.2 2981 PF9F2R2K98 116700 Powerohm
9.2 3751 PF9F2R3K75 135600 Powerohm
9.2 4867 PF9F2R4K86 282100 Powerohm
9.2 6601 PF9F2R6K60 341800 Powerohm
9.2 7737 PF9F2R7K73 748700 Powerohm
9.2 9421 PF9F2R9K42 1075400 Powerohm
9.2 11923 PF9F2R11K9 1520800 Powerohm
9.2 15001 PF9F2R15K0 545200 Powerohm
9.2 19467 PF9F2R19K4 1064100 Powerohm
9.2 24876 PF9F2R24K8 1416000 Powerohm
9.2 30948 PF9F2R30K9 2965500 Powerohm
9.2 37683 PF9F2R37K6 4056800 Powerohm
9.2 47693 PF9F2R47K6 6146600 Powerohm
9.2 58880 PF9F2R58K8 10387700 Powerohm
9.2 69635 PF9F2R69K6 6672400 Powerohm
9.2 90001 PF9F2R90K0 9127700 Powerohm
9.2 132480 PF9F2R132K2 23372300 Powerohm
8 14093 442-16A 401656 IPC
8 21143 442-16 693480 IPC
8 23427 552-18A 1211023 IPC
8 31474 445-16A 1564893 IPC
8 35138 552-18 2494758 IPC
8 46977 440-16A 2966898 IPC
8 47219 445-16 1560331 IPC
8 52321 555-18A 1559677 IPC
8 70477 440-16 3325398 IPC
8 78475 555-18 5345909 IPC
7.3 3826 222-10A 164245 IPC
7.3 5095 222-10 267369 IPC
7.3 8545 225-10A 566990 IPC
7.3 12738 225-10 359925 IPC
7.3 12754 220-10A 359925 IPC
7.3 19264 220-10 656981 IPC
7 400 PF7R400W 19300 Powerohm
7 800 PF7R800W 35900 Powerohm
7 1200 PF7R1K20 123900 Powerohm
7 1600 PF7R1K60 77000 Powerohm
Ohms Watts Catalog
Watt
Seconds
Manufacturer
7 2268 PF7R2K26 77800 Powerohm
7 2800 PF7R2K80 107500 Powerohm
7 3703 PF7R3K70 199600 Powerohm
7 4732 PF7R4K73 300300 Powerohm
7 6240 PF7R6K23 599000 Powerohm
7 7383 PF7R7K38 765100 Powerohm
7 9307 PF7R9K30 1303500 Powerohm
7 11251 PF7R11K2 436200 Powerohm
7 14812 PF7R14K8 802700 Powerohm
7 18928 PF7R18K9 1132800 Powerohm
7 23548 PF7R23K5 2330100 Powerohm
7 28672 PF7R28K6 3042600 Powerohm
7 36912 PF7R36K9 4610000 Powerohm
7 45001 PF7R45K0 7990600 Powerohm
7 55001 PF7R55K0 5083700 Powerohm
7 64512 PF7R64K5 6845800 Powerohm
7 81648 PF7R81K6 10141900 Powerohm
7 110001 PF7R110K0 17978700 Powerohm
7 127575 PF7R127K7 21021300 Powerohm
7 157500 PF7R157K7 34493700 Powerohm
6.5 2106 PF6F5R2K10 92600 Powerohm
6.5 2600 PF6F5R2K60 90400 Powerohm
6.5 3438 PF6F5R3K43 188100 Powerohm
6.5 4394 PF6F5R4K39 256400 Powerohm
6.5 5466 PF6F5R5K46 599000 Powerohm
6.5 6656 PF6F5R6K65 717000 Powerohm
6.5 8424 PF6F5R8K42 1086300 Powerohm
6.4 17529 442-17A 574859 IPC
6.4 26292 442-17 719851 IPC
6.4 39148 445-17A 1231840 IPC
6.4 58430 440-17A 4818224 IPC
6.4 58718 445-17 4929414 IPC
6 28008 552-19A 1960167 IPC
6 42015 552-19 1981674 IPC
6 62551 555-19A 2135190 IPC
5.7 4938 222-11A 260816 IPC
5.7 6525 222-11 421193 IPC
5.7 11029 225-11A 905640 IPC
5.7 16314 225-11 880744 IPC
5.7 16461 220-11A 880744 IPC
5.7 24694 220-11 1781970 IPC
5.4 1670 T5F4R1K67 55700 IPC
5.4 2680 T5F4R2K68 185000 IPC
5.4 5080 T5F4R5K8 401000 IPC
5.4 5780 T5F4R5K78 169000 IPC
5.4 7280 T5F4R7K28 328000 IPC
5.4 12000 T5F4R12K0 699000 IPC
5.4 20300 T5F4R20K3 738000 IPC
5.4 22000 T5F4R22K0 717000 IPC
5.4 37700 T5F4R37K7 2310000 IPC
5.4 48100 T5F4R48K1 1845000 IPC
5.4 51900 T5F4R51K9 1953000 IPC
5.4 104000 T5F4R104K0 3444000 IPC
5.1 400 PF5F1R400W 35400 Powerohm
5.1 800 PF5F1R800W 41100 Powerohm
5.1 1600 PF5F1R1K60 141300 Powerohm
5.1 2704 PF5F1R2K70 158300 Powerohm
5.1 3448 PF5F1R3K44 212400 Powerohm
5.1 4290 PF5F1R4K29 449300 Powerohm
5.1 5408 PF5F1R5K40 537700 Powerohm
5.1 6610 PF5F1R6K60 869000 Powerohm
5.1 8160 PF5F1R8K16 1412200 Powerohm
5.1 10791 PF5F1R10K7 564200 Powerohm
5.1 13790 PF5F1R13K7 800800 Powerohm
5.1 17156 PF5F1R17K1 1694600 Powerohm
5.1 27501 PF5F1R27K5 3380700 Powerohm
5.1 32640 PF5F1R32K6 5992900 Powerohm
Ohms Watts Catalog
Watt
Seconds
Manufacturer
