9
Chapter
9-1
Local and Serial Port Parameter Settings
Firmware Version 1.01Ć3.01
Table 9 -- Parameter List for Parameters 0 to 50
Parameters 0 to 50 can be accessed through either the local or serial port.
Local
Programming
Serial
Panel
Port
Parameter Parameter
Min/Max
Min/Max
Factory
Number
Text
Units
Values
Values
Setting
0
PARAMETER MODE
None
0/0
0/0
0
1
OUTPUT VOLTS
Volts
0/575
0/575
0
2
OUTPUT CURRENT
% of Rated Output Current
0/200
0/200
0
3
OUTPUT POWER
% of Rated Output Power
0/200
0/200
0
4
LAST FAULT
Code
0/37
0/37
0
5
FREQUENCY SELECT 1
Code
0/5
0/5
0
6
FREQUENCY SELECT 2
Code
0/5
0/5
0
7
ACCEL TIME 1
Seconds
0/600
0.00/600.00
5
8
DECEL TIME 1
Seconds
0/600
0.00/600.00
5
9
DC BOOST SELECT
Code
0/1
0/12
2
10
STOP SELECT
Code
0/2
0/2
0
11
DECEL FREQUENCY HOLD
Off/On
0/1
0/1
0
12
DC HOLD TIME
Seconds
0/15
0/15
0
13
DC HOLD VOLTS
Volts
0/115
0/115
0
14
AUTO RESTART
Off/On
0/1
0/1
1
15
FACTORY SET -- DO NOT CHANGE None
0/0
0/0
0
16
MINIMUM FREQUENCY
Hertz
0/120
0/120
0
17
BASE FREQUENCY
Hertz
40/120
40/120
60
18
BASE VOLTS
Volts
115/575
115/575
460
19
MAXIMUM FREQUENCY
Hertz
40/250
40/250
60
20
MAXIMUM VOLTS
Volts
115/575
115/575
460
21
LOCAL RUN
Off/On
0/1
0/1
1
22
LOCAL REVERSE
Off/On
0/1
0/1
1
23
LOCAL JOG
Off/On
0/1
0/1
1
24
JOG FREQUENCY
Hertz
.0/120
0.00/120.00
.0
25
ANALOG OUTPUT
Code
0/1
0/1
0
26
PRESET/2ND ACCEL
Code
0/1
0/1
0
27
PRESET FREQUENCY 1
Hertz
.0/250
0.00/250.00
.0
28
PRESET FREQUENCY 2
Hertz
.0/250
0.00/250.00
.0
29
PRESET FREQUENCY 3
Hertz
.0/250
0.00/250.00
.0
