Overload Current Settings
Chapter 6
6-2
Table 6 -- Overload Current Settings for 1336VT Drives
Parameter 38 MOTOR FULL LOAD CURRENT RATING
Setting B003 B005 B007 B010 B015 B020 B025 B030 B040 B050 B060 B075 B100 B125 B150 B200 B250
50 2.50 4.00 5.50 7.00 10.5 13.5 17.0 20.0 26.0 32.5 38.5 48 62 78 90 120 150
51 2.55 4.08 5.61 7.14 10.7 13.8 17.3 20.4 26.5 33.2 39.3 49 63 80 92 122 153
52 2.60 4.16 5.72 7.28 10.9 14.0 17.7 20.8 27.0 33.8 40.0 50 64 81 94 125 156
53 2.65 4.24 5.83 7.42 11.1 14.3 18.0 21.2 27.6 34.5 40.8 51 66 83 95 127 159
54 2.70 4.32 5.94 7.56 11.3 14.6 18.4 21.6 28.1 35.1 41.6 52 67 84 97 130 162
55 2.75 4.40 6.05 7.70 11.6 14.9 18.7 22.0 28.6 35.8 42.4 53 68 86 99 132 165
56 2.80 4.48 6.16 7.84 11.8 15.1 19.0 22.4 29.1 36.4 43.1 54 69 87 101 134 168
57 2.85 4.56 6.27 7.98 12.0 15.4 19.4 22.8 29.6 37.1 43.9 55 71 89 103 137 171
58 2.90 4.64 6.38 8.12 12.2 15.7 19.7 23.2 30.2 37.7 44.7 56 72 90 104 139 174
59 2.95 4.72 6.49 8.26 12.4 15.9 20.1 23.6 30.7 38.4 45.4 57 73 92 106 142 177
60 3.00 4.80 6.60 8.40 12.6 16.2 20.4 24.0 31.2 39.0 46.2 58 74 94 108 144 180
61 3.05 4.88 6.71 8.54 12.8 16.5 20.7 24.4 31.7 39.7 47.0 59 76 95 110 146 183
62 3.10 4.96 6.82 8.68 13.0 16.7 21.1 24.8 32.2 40.3 47.7 60 77 97 112 149 186
63 3.15 5.04 6.93 8.82 13.2 17.0 21.4 25.2 32.8 41.0 48.5 60 78 98 113 151 189
64 3.20 5.12 7.04 8.96 13.4 17.3 21.8 25.6 33.3 41.6 49.3 61 79 100 115 154 192
65 3.25 5.20 7.15 9.10 13.7 17.6 22.1 26.0 33.8 42.3 50.1 62 81 101 117 156 195
66 3.30 5.28 7.26 9.24 13.9 17.8 22.4 26.4 34.3 42.9 50.8 63 82 103 119 158 198
67 3.35 5.36 7.37 9.38 14.1 18.1 22.8 26.8 34.8 43.6 51.6 64 83 105 121 161 201
68 3.40 5.44 7.48 9.52 14.3 18.4 23.1 27.2 35.4 44.2 52.4 65 84 106 122 163 204
69 3.45 5.52 7.59 9.66 14.5 18.6 23.5 27.6 35.9 44.9 53.1 66 86 108 124 166 207
70 3.50 5.60 7.70 9.80 14.7 18.9 23.8 28.0 36.4 45.5 53.9 67 87 109 126 168 210
71 3.55 5.68 7.81 9.94 14.9 19.2 24.1 28.4 36.9 46.2 54.7 68 88 111 128 170 213
72 3.60 5.76 7.92 10.08 15.1 19.4 24.5 28.8 37.4 46.8 55.4 69 89 112 130 173 216
73 3.65 5.84 8.03 10.22 15.3 19.7 24.8 29.2 38.0 47.5 56.2 70 91 114 131 175 219
74 3.70 5.92 8.14 10.36 15.5 20.0 25.2 29.6 38.5 48.1 57.0 71 92 115 133 178 222
75 3.75 6.00 8.25 10.50 15.8 20.3 25.5 30.0 39.0 48.8 57.8 72 93 117 135 180 225
76 3.80 6.08 8.36 10.64 16.0 20.5 25.8 30.4 39.5 49.4 58.5 73 94 119 137 182 228
77 3.85 6.16 8.47 10.78 16.2 20.8 26.2 30.8 40.0 50.1 59.3 74 95 120 139 185 231
78 3.90 6.24 8.58 10.92 16.4 21.1 26.5 31.2 40.6 50.7 60.1 75 97 122 140 187 234
79 3.95 6.32 8.69 11.06 16.6 21.3 26.9 31.6 41.1 51.4 60.8 76 98 123 142 190 237
80 4.00 6.40 8.80 11.20 16.8 21.6 27.2 32.0 41.6 52.0 61.6 77 99 125 144 192 240
81 4.05 6.48 8.91 11.34 17.0 21.9 27.5 32.4 42.1 52.7 62.4 78 100 126 146 194 243
82 4.10 6.56 9.02 11.48 17.2 22.1 27.9 32.8 42.6 53.3 63.1 79 102 128 148 197 246
83 4.15 6.64 9.13 11.62 17.4 22.4 28.2 33.2 43.2 54.0 63.9 80 103 129 149 199 249
84 4.20 6.72 9.24 11.76 17.6 22.7 28.6 33.6 43.7 54.6 64.7 81 104 131 151 202 252
85 4.25 6.80 9.35 11.90 17.9 23.0 28.9 34.0 44.2 55.3 65.5 82 105 133 153 204 255
86 4.30 6.88 9.46 12.04 18.1 23.2 29.2 34.4 44.7 55.9 66.2 83 107 134 155 206 258
87 4.35 6.96 9.57 12.18 18.3 23.5 29.6 34.8 45.2 56.6 67.0 84 108 136 157 209 261
88 4.40 7.04 9.68 12.32 18.5 23.8 29.9 35.2 45.8 57.2 67.8 84 109 137 158 211 264
89 4.45 7.12 9.79 12.46 18.7 24.0 30.3 35.6 46.3 57.9 68.5 85 110 139 160 214 267
90 4.50 7.20 9.90 12.60 18.9 24.3 30.6 36.0 46.8 58.5 69.3 86 112 140 162 216 270
91 4.55 7.28 10.01 12.74 19.1 24.6 30.9 36.4 47.3 59.2 70.1 87 113 142 164 218 273
92 4.60 7.36 10.12 12.88 19.3 24.8 31.3 36.8 47.8 59.8 70.8 88 114 144 166 221 276
93 4.65 7.44 10.23 13.02 19.5 25.1 31.6 37.2 48.4 60.5 71.6 89 115 145 167 223 279
94 4.70 7.52 10.34 13.16 19.7 25.4 32.0 37.6 48.9 61.1 72.4 90 117 147 169 226 282
95 4.75 7.60 10.45 13.30 20.0 25.7 32.3 38.0 49.4 61.8 73.2 91 118 148 171 228 285
96 4.80 7.68 10.56 13.44 20.2 25.9 32.6 38.4 49.9 62.4 73.9 92 119 150 173 230 288
97 4.85 7.76 10.67 13.58 20.4 26.2 33.0 38.8 50.4 63.1 74.7 93 120 151 175 233 291
98 4.90 7.84 10.78 13.72 20.6 26.5 33.3 39.2 51.0 63.7 75.5 94 122 153 176 235 294
99 4.95 7.92 10.89 13.86 20.8 26.7 33.7 39.6 51.5 64.4 76.2 95 123 154 178 238 297
100 5.00 8.00 11.00 14.00 21.0 27.0 34.0 40.0 52.0 65.0 77.0 96 124 156 180 240 300
101 5.05 8.08 11.11 14.14 21.2 27.3 34.3 40.4 52.5 65.7 77.8 97 125 158 182 242 303
102 5.10 8.16 11.22 14.28 21.4 27.5 34.7 40.8 53.0 66.3 78.5 98 127 159 184 245 306
103 5.15 8.24 11.33 14.42 21.6 27.8 35.0 41.2 53.6 67.0 79.3 99 128 161 185 247 309
104 5.20 8.32 11.44 14.56 21.8 28.1 35.4 41.6 54.1 67.6 80.1 100 129 162 187 250 312
105 5.25 8.40 11.55 14.70 22.1 28.4 35.7 42.0 54.6 68.3 80.9 101 130 164 189 252 315
106 5.30 8.48 11.66 14.84 22.3 28.6 36.0 42.4 55.1 68.9 81.6 102 131 165 191 254 318
107 5.35 8.56 11.77 14.98 22.5 28.9 36.4 42.8 55.6 69.6 82.4 103 133 167 193 257 321
108 5.40 8.64 11.88 15.12 22.7 29.2 36.7 43.2 56.2 70.2 83.2 104 134 169 194 259 324
109 5.45 8.72 11.99 15.26 22.9 29.4 37.1 43.6 56.7 70.9 83.9 105 135 170 196 262 327
110 5.50 8.80 12.10 15.40 23.1 29.7 37.4 44.0 57.2 71.5 84.7 106 136 172 198 264 330
111 5.55 8.88 12.21 15.54 23.3 30.0 37.7 44.4 57.7 72.2 85.5 107 138 173 200 266 333
112 5.60 8.96 12.32 15.68 23.5 30.2 38.1 44.8 58.2 72.8 86.2 108 139 175 202 269 336
113 5.65 9.04 12.43 15.82 23.7 30.5 38.4 45.2 58.8 73.5 87.0 109 140 177 203 271 339
114 5.70 9.12 12.54 15.96 23.9 30.8 38.8 45.6 59.3 74.1 87.8 109 141 178 205 274 342
115 5.75 9.20 12.65 16.10 24.2 31.1 39.1 46.0 59.8 74.8 88.6 110 143 179 207 276 345
