Sw1 operation – Rockwell Automation 1336VT AC DRIVE 5-300AMP (2-160KW) PROGRAMMING MANUAL User Manual
Page 13

Local Parameter Programming
Chapter 1
1-2
SW1 Operation
SW1 is a rocker switch only accessible on the chassis mounted Local
Programming and Display Panel. The switch can be accessed only with the
drive cover removed and may be used to disable the Enter pushbutton and
control access to local programming.
ENABLED
C1
C2
➀
➁
SW1
Enter
Enter button enabled — Access to programming allowed if SW1 is set to
position C1.
Enter
SW1
DISABLED
C1
C2
➀
➁
Enter
Enter button disabled — Access to programming not allowed if SW1 is
set to position C2
