Chapter 3
Receiving, Unpacking and Inspection
3-6
Code
1:1
1:2
1:2.5
1:5
255
256
424
425
800
801
Feedback Coupling 7
1326 MOD C1
First Position Second Position Third Position
Bulletin
Number
Type
Coupling
Size
–
Description
Modifica-
tion Kit
Code
MOD
Code
C1
C2
Size – Motor Shaft to Encoder Shaft
3/8” to 3/8” (9.5 mm to 9.5 mm) –
Standard on all 1326AB Motors
1/4” to 3/8” (6.4 mm to 9.5 mm)
–
7 The feedback coupling is included as standard with all Feedback Mounting Adapter Kits.
8 Kit includes Resolver Feedback Package, mounting hardware and 3/8” to 3/8” (9.5 mm to 9.5 mm) resolver to motor mounting coupling.
1326AB MOD
First Position Second Position Third Position
Bulletin
Number Gear Ratio
Input:Resolver
–
Description
Modifica-
tion Kit
8
Code
MOD
VC
Type
Resolver Feedback Package
–
Description
Single device format – 1 turn of the motor shaft to 1 turn of the resolver.
Single device format – 1 turn of the motor shaft to 2 turns of the resolver.
Single device format – 1 turn of the motor shaft to 2.5 turns of the resolver.
Single device format – 1 turn of the motor shaft to 5 turns of the resolver.
Absolute master/vernier format – 1:1 input/master, 255:256 master/vernier
for IMC 120, 121, 123 only.
Absolute master/vernier format – 1:1 input/master, 256:255 master/vernier
for 8600 series and MAX, IMC S class controls with a REC 4096 Board.
Absolute master/vernier format – 1:1 input/master, 424:425 master/vernier
for IMC 120, 121, 123 only.
Absolute master/vernier format – 1:1 input/master, 425:424 master/vernier
for 8600 series and MAX, IMC S class controls with a REC 4096 Board.
Absolute master/vernier format – 1:1 input/master, 800:801 master/vernier
for IMC 120, 121, 123 only.
Absolute master/vernier format – 1:1 input/master, 801:800 master/vernier
for 8600 series controllers (is not applicable for use with MAX and IMC S
Class controls)
1:1
Fourth Position
Resolver Feedback
Package
Code
VC
VD
Description
4.25” (108 mm) feedback package with cast
housing and single or vernier (dual) format with
receiver (Harowe 11BRW-300-F-58A or equivalent)
type resolver(s) for use with A-B series 8200 CNC
and IMC
] 120, 121, 123.
4.25” (108 mm) feedback package with cast
housing and single or vernier (dual) format with
transmitter (Harowe 11BRCX-300-C10/6 or
equivalent) type resolver(s) for use with A-B series
8600, MAX and IMC S Class controllers with a
REC 4096 Board.
