Rockwell Automation 865 Differential Protection Relay - Manual (Page 163)

Connections 9-3
865-UM001A-EN-P – July 2009
Terminal X2 without the analogue output
No: Symbol Description
1 -- --
2 -- --
3 -- --
4 -- --
5 A5 Alarm relay 5
6 A5 Alarm relay 5
7 A4 Alarm relay 4
8 A4 Alarm relay 4
9 -- --
10 A3 COM Alarm relay 3, common connector
11 A3 NC Alarm relay 3, normal closed connector
12 A3 NO Alarm relay 3, normal open connector
13 A2 COM Alarm relay 2, common connector
14 A2 NC Alarm relay 2, normal closed connector
15 A2 NO Alarm relay 2, normal open connector
16 IF COM Internal fault relay, common connector
17 IF NC Internal fault relay, normal closed connector
18 IF NO Internal fault relay, normal open connector
Terminal X2 with the analogue output
No: Symbol Description
1 AO1+ Analogue output 1, common positive connector
2 AO1 Analogue output 1, negative connector
3 AO2+ Analogue output 2, common positive connector
4 AO2 Analogue output 2, negative connector
5 AO3+ Analogue output 3, common positive connector
6 AO3 Analogue output 3, negative connector
7 AO4+ Analogue output 4, common positive connector
8 AO4 Analogue output 4, negative connector
9 -- --
10 A3 COM Alarm relay 3, common connector
11 A3 NC Alarm relay 3, normal closed connector
12 A3 NO Alarm relay 3, normal open connector
13 A2 COM Alarm relay 2, common connector
14 A2 NC Alarm relay 2, normal closed connector
15 A2 NO Alarm relay 2, normal open connector
16 IF COM Internal fault relay, common connector
17 IF NC Internal fault relay, normal closed connector
18 IF NO Internal fault relay, normal open connector
