Rockwell Automation 20-750-CNETC PowerFlex Coaxial ControlNet Option Module User Manual
Page 93

Rockwell Automation Publication 750COM-UM003B-EN-P - November 2012
93
Troubleshooting
Chapter 7
27
DL To Net 01 Val
The present value of respective Host DL To Net xx parameter being received from the drive by this option
module. (If not using a Datalink, its respective value should be zero.)
28
DL To Net 02 Val
29
DL To Net 03 Val
30
DL To Net 04 Val
31
DL To Net 05 Val
32
DL To Net 06 Val
33
DL To Net 07 Val
34
DL To Net 08 Val
35
DL To Net 09 Val
36
DL To Net 10 Val
37
DL To Net 11 Val
38
DL To Net 12 Val
39
DL To Net 13 Val
40
DL To Net 14 Val
41
DL To Net 15 Val
42
DL To Net 16 Val
43
DPI Rx Errs
The present value of the DPI Receive error counter.
44
DPI Rx Errs Max
The maximum value (since reset) of the DPI Receive Error counter.
45
DPI Tx Errs
The present value of the DPI Transmit error counter.
46
DPI Tx Errs Max
The maximum value (since reset) of the DPI Transmit Error counter.
47
CN Rx Packets
A count of the number of network packets received by the option module.
48
CN Rx Underflows
A count of the number of network receive underflow errors.
49
CN Rx Overflows
A count of the number of network receive overflow errors.
50
CN Rx Bad Frames
A count of the number of network receive bad frame errors.
51
CN Tx Packets
A count of the number of network packets transmitted by the option module.
52
CN Tx Underflows
A count of the number of network transmit underflow errors.
53
CN Tx Overflows
A count of the number of network transmit overflow errors.
54
CN Tx OutOfSteps
A count of the number of network transmit out-of-step errors.
55
CN Tx Blockages
A count of the number of network transmit blockage errors.
56
Boot Flash Count
Number of times the boot firmware in the option module has been updated.
57
App Flash Count
Number of times the application firmware in the option module has been updated.
58
Net Addr Sw
The present value of the node address switches.
Table 11 - Option Module Diagnostic Items (Continued)
No.
Name
Description
