Ordering information, Chapter, Safety camera systems – Rockwell Automation 442L SC300 Safety Sensor User Manual User Manual
Page 54
52
Rockwell Automation Publication 10000202762 Ver 00 - January 2012
Chapter 12
Ordering information
Chapter
12
Ordering information
Safety camera systems
Note
In addition to the safety camera system, you will require one of the resolution sets.
Table 16 - Part numbers safety camera systems
Description
Part number
SC300 Safety camera system consisting of
camera, teach-in pin, label “Important Information”, operating instructions on CDROM
and QuickStart (instructions for quick commissioning), multi-lingual
442L-SAFCAM1
Resolution sets
consisting of test rod (to suit the resolution) and 2 reflector strips
Resolution set for resolution of 20 mm
442L-ACAM20MMKIT
Resolution set for resolution of 24 mm
442L-ACAM24MMKIT
Resolution set for resolution of 30 mm
442L-ACAM30MMKIT
Ordering example
If an SC300 safety camera is to be used in your application with a resolution of 20 mm.
Then you must order the following:
•
SC300 safety camera (Cat. 3, PL d according to EN ISO 138491)
442L-SAFCAM1
•
Resolution set for resolution of 20 mm
442L-ACAM20MMKIT
