198 Rockwell Automation Publication 23C-IN001B-EN-P - June 2013
Appendix B Replacement Parts
NEMA/UL Type 3R
Control Transformer T1 208V AC 3.0…30 TB-69302
(1)
45…50 TB-69303 (1)
460V AC 3.0…40 TB-69302 (1)
50…150 TB-69303
(1)
Control Transformer Fuse
Holder 208V AC 3.0…30 PL-112701
(1)
40…50 PL-112702
(1)
460V AC 3.0…40 PL-112701 (1)
50…150 PL-112702
(1)
Control Transformer Primary
Fuses FU4…FU5 208V AC 3.0…30 ATQR-2
40…50 ATQR-3.5
460V AC 3.0…40 ATQR-1
50…150 ATQR-1.5
Control Circuit Fan Fuse Holder 208V AC 3.0…50 BM6031PQ
460V AC 3.0…5.0 No Fan
7.5…150 BM6031PQ
Control Circuit Fan Fuse FU6 208V AC 3.0…50 FNM-1
460V AC 3.0…100 FNM-1
125…150 FNM-2
Fan & Filter 208V AC 3.0…10 SCE-FA44
(4)
15…30 SCE-FA66 (4)
40…50 SCE-FA1010 (4)
460V AC 3.0…5.0 No Fan
7.5…20 SCE-FA44
(4)
25…40 SCE-FA66 (4)
50…150 SCE-FA1010 (4)
Exhaust Filter w/Grille 208V AC 3.0…10 SCE-FGA44
(4)
15…30 SCE-FGA66
(4)
40…50 SCE-FGA1010 (4)
460V AC 3.0…5.0 No Filter
7.5…20 SCE-FGA44
(4)
25…40 SCE-FGA66
(4)
50…150 SCE-FGA1010 (4)
Filter Media 208V AC 3.0…10 SCE-RF44 (4)
15…20 SCE-RF66
(4)
25…50 SCE-RF1010
(4)
460V AC 3.0…5.0 No Filter
7.5…20 SCE-RF44 (4)
25…40 SCE-RF66
(4)
50…150 SCE-RF1010
(4)
Control Circuit Heater Fuse
Holder 208V AC 3.0…50 BM6031PQ
460V AC 3.0…150 BM6031PQ
Control Circuit Heater Fuse FU7 208V AC 3.0…20 FNM-2
25…50 FNM-3.2
460V AC 3.0…40 FNM-2
50…150 FNM-3.2
Heater 208V AC 3.0…20 D-AH1001A
(5)
25…50 D-AH2001A
(5)
460V AC 3.0…40 D-AH1001A (5)
50…150 D-AH2001A
(5)
Description Designation Voltage Hp Part Number
