Replacement Parts
Appendix B
Input Contactor
DIC
208V AC
3.0…5.0
100-C16D10
7.5…10
100-C23D10
15
100-C60D10
20
100-C72D00
25…30
100-C85D00
40
100-D115ED11
50
100-D140ED11
460V AC
3.0…10
100-C16D10
15…20
100-C23D10
25…30
100-C43D00
40…50
100-C72D00
60
100-C85D00
75…100
100-D115ED11
125
100-D140ED11
150…200
100-D210ED11
250
100-D300ED11
300…350
100-D420ED11
Output Contactor
DOC
208V AC
3.0…7.5
100-C16D10
10
100-C23D10
15
100-C37D00
20
100-C43D00
25…30
100-C72D00
40…50
100-D115ED11
460V AC
3.0…20
100-C16D10
25…30
100-C37D00
40
100-C43D00
50…60
100-C72D00
75
100-C85D00
100…125
100-D115ED11
150
100-D140ED11
200
100-D210ED11
250
100-D300ED11
300…350
100-D420ED11
Contactor Suppressors
230V AC
3.0…30
100-FSV136
460V AC
3.0…75
100-FSV136
Overload Relay
OL
208V AC
3.0
193-EEDB
5.0
193-EEEB
7.5
193-EEED
10
193-EEED
15…25
193-EEGE
30…40
193-EEVF
50
193-EEJF
460V AC
3.0
193-EECB
5.0…7.5
193-EEDB
10
193-EEEB
15
193-EEED
20…30
193-EEFD
40…60
193-EEGE
75
193-EEVF
100…125
193-EEJF
150
193-EEJG
200…350
193-EELG
Bypass Control Panel
CP1
208V AC
3.0…50
SK-C1-BCP1
460V AC
3.0…350
SK-C1-BCP1
Description
Designation
Voltage
Hp
Part Number
