Publication 20D-UM002C-EN-P - November 2003
Placing and Configuring the Drive 3-7
The following tables show the tag names and their relation ship to parameters
in the drive. These examples use a module name of “drive_module”.
Table 3.1 Mapping for the Velocity Control Communication Format
DriveLogix Controller Outputs PowerFlex 700S Inputs
Tag Name
Data
Type Parameter Linked Parameter
Number Name Name Number
drive_module:O.LogicCommand DINT 600 Integer In00 Logic Command 151
drive_module:O.SpeedRef1 REAL 603 Real In01 Speed Ref 1 10
drive_module:O.TorqueRef1 DINT 605 Real In02 Torque Ref 1 111
drive_module:O.SpdTorqModeSel DINT 606 Integer In03 Spd/Trq ModeSel 110
drive_module:O.TorqueStep REAL 609 Real In04 Torque Step 116
drive_module:O.SpdRegDroop REAL 611 Real In05 Spd Reg Droop 86
drive_module:O.UserDefinedRealData[0] REAL 613 Real In06
drive_module:O.UserDefinedRealData[1] REAL 615 Real In07
drive_module:O.UserDefinedRealData[2] REAL 617 Real In08
drive_module:O.UserDefinedRealData[3] REAL 619 Real In09
drive_module:O.UserDefinedRealData[4] REAL 621 Real In10
drive_module:O.UserDefinedRealData[5] REAL 623 Real In11
drive_module:O.UserDefinedRealData[6] REAL 625 Real In12
drive_module:O.UserDefinedIntegerData[0] DINT 626 Integer In13
drive_module:O.UserDefinedIntegerData[1] DINT 628 Integer In14
drive_module:O.UserDefinedIntegerData[2] DINT 630 Integer In15
DriveLogix Controller Inputs PowerFlex 700S Outputs
Tag Name
Data
Type Parameter Linked Parameter
Number Name Name Number
drive_module:I.LogicStatus DINT 632 Integer Out00 Logic Status 155
drive_module:I.FilteredSpdFdbk REAL 635 Real Out01 Filtered SpdFdbk 71
drive_module:I.MotorTorqueRef REAL 637 Real Out02 Motor Torque Ref 303
drive_module:I.OutputCurrent REAL 639 Real Out03 Output Current 308
drive_module:I.MCStatus DINT 640 Integer Out04 MC Status 555
drive_module:I.LocalIOStatus DINT 642 Integer Out05 Local I/O Status 824
drive_module:I.UserDefinedRealData[0] REAL 645 Real Out06
drive_module:I.UserDefinedRealData[1] REAL 647 Real Out07
drive_module:I.UserDefinedRealData[2] REAL 649 Real Out08
drive_module:I.UserDefinedRealData[3] REAL 651 Real Out09
drive_module:I.UserDefinedRealData[4] REAL 653 Real Out10
drive_module:I.UserDefinedRealData[5] REAL 655 Real Out11
drive_module:I.UserDefinedRealData[6] REAL 657 Real Out12
drive_module:I.UserDefinedIntegerData[0] DINT 658 Integer Out13
drive_module:I.UserDefinedIntegerData[1] DINT 660 Integer Out14
drive_module:I.UserDefinedIntegerData[2] DINT 662 Integer Out15
