1 Publication 20D-UM002C-EN-P - November 2003
Chapter
6
Communicating with Devices on an
EtherNet/IP Link
Using This Chapter
Configuring Your System for
a EtherNet/IP Link For the DriveLogix controller to operate on an Ethernet network, you need:
• a workstation with an appropriate EtherNet/IP
communication daughtercard
• a 1788-ENBT communication daughtercard installed in the DriveLogix
communication slot
• RSLinx software to configure the EtherNet/IP communication driver
• RSLogix 5000 programming software (Version 11 or later) to configure
the 1788-ENBT communication daughtercard as part of the DriveLogix
system
For information about: See page
Configuring Your System for a EtherNet/IP Link 6-1
Configuring Remote I/O 6-8
Sending Messages 6-13
Producing and Consuming Data 6-20
Guidelines for Configuring Connections 6-23
Example 1: DriveLogix Controller and Remote I/O 6-23
Example 1: DriveLogix Controller and Remote I/O 6-25
Example 3: DriveLogix Controller to Other Devices 6-29
IMPORTANT
Unlike ControlNet, the EtherNet/IP network requires no
scheduling.
