Adapter Parameters B-5
35 PIDD W7 Actual
Actual Process Input Data Description for Word 7. Value: See Table B.1
Type: Read Only
36 PIDD W8 Cfg
Configured Process Input Data Description for
Word 8. PCP Object to use for Word 8 transmitted
to Interbus master. Default: 0
Setting: See Table B.1
Type: Read/Write
Reset Required: No (becomes active
when Interbus network
is restarted)
37 PIDD W8 Actual
Actual Process Input Data Description for Word 8. Value: See Table B.1
Type: Read Only
38 PODD W0 Cfg
Configured Process Output Data Description for
Word 0. PCP Object to use for Word 0 received
from Interbus master. Default: 0x2F98
(Logic Command)
Setting: See Table B.1
Type: Read/Write
Reset Required: No (becomes active
when Interbus network
is restarted)
39 PODD W0 Actual
Actual Process Output Data Description for Word
0. Value: See Table B.1
Type: Read Only
40 PODD W1 Cfg
Configured Process Output Data Description for
Word 1. PCP Object to use for Word 1 received
from Interbus master. Default: 0x2F99
(Reference)
Setting: See Table B.1
Type: Read/Write
Reset Required: No (becomes active
when Interbus network
is restarted)
41 PODD W1 Actual
Actual Process Output Data Description for Word
1. Value: See Table B.1
Type: Read Only
42 PODD W2 Cfg
Configured Process Output Data Description for
Word 2. PCP Object to use for Word 2 received
from Interbus master. Default: 0
Setting: See Table B.1
Type: Read/Write
Reset Required: No (becomes active
when Interbus network
is restarted)
43 PODD W2 Actual
Actual Process Output Data Description for Word
2. Value: See Table B.1
Type: Read Only
44 PODD W3 Cfg
Configured Process Output Data Description for
Word 3. PCP Object to use for Word 3 received
from Interbus master. Default: 0
Setting: See Table B.1
Type: Read/Write
Reset Required: No (becomes active
when Interbus network
is restarted)
45 PODD W3 Actual
Actual Process Output Data Description for Word
3. Value: See Table B.1
Type: Read Only
46 PODD W4 Cfg
Configured Process Output Data Description for
Word 4. PCP Object to use for Word 4 received
from Interbus master. Default: 0
Setting: See Table B.1
Type: Read/Write
Reset Required: No (becomes active
when Interbus network
is restarted)
Parameter
No. Name and Description
Details
