Configuring the Adapter 3-7
To set the fault configuration parameters
If you set Parameter 6 - [Comm Flt Action] to the “Send Flt Cfg,” the
values in the following parameters are sent to the drive after a
communications fault occurs. You must set these parameters to values
required by your application.
Changes to these parameters take effect immediately. A reset is not
required.
Changes to switch settings or some adapter parameters require that you
reset the adapter before the new settings take effect. You can reset the
adapter by cycling power to the drive or by using the following
parameter:
• Set the Parameter 05 - [Reset Module] to Reset Module:
Figure 3.3 Reset Screen on an LCD HIM
When you enter 1 = Reset Module, the adapter will be immediately
reset. When you enter 2 = Set Defaults, the adapter will set all adapter
parameters to their factory-default settings. The value of this parameter
will be restored to 0 = Ready after the adapter is reset.
Number Name Description
10 Flt Cfg Logic A 16-bit value sent to the drive for Logic Command.
11 Flt Cfg Ref A 32-bit value (0 – 4294967295) sent to the drive as a
Reference or Datalink.
Important: If the drive uses a 16-bit Reference or 16-bit
Datalinks, the most significant word of the value must be
set to zero (0) or a fault will occur.
12 – 19 Flt Cfg x1 In
Resetting the Adapter
!
ATTENTION: Risk of injury or equipment damage exists. If the
adapter is transmitting control I/O to the drive, the drive may fault when
you reset the adapter. Determine how your product will respond before
resetting a connected adapter.
Value Description
0 Ready (Default)
1 Reset Module
2 Set Defaults
Port 5 Device
20-COMM-I
Parameter #: 5
Reset Module
1
Reset Module
