7-4 Troubleshooting
Adapter Diagnostic Items are viewable with DriveExplorer (version 2.01
or higher), DriveExecutive (version v1.01 or higher) or LCD HIM (2.001
or higher) software. Diagnostic items show current data being
transmitted and received by the Host device (e.g. drive), and other
diagnostic information regarding the 20-COMM-I.
Adapter Diagnostic Items
No. Event Description
1 Common Logic Cmd The current value of the Common Logic Command being transmitted
to the Host.
2 Prod Logic Cmd The current value of the Product-Specific Logic Command being
transmitted to the Host.
3 Reference The current value ofthe Product-Specific Reference being
transmitted to the Host.
4 Common Logic Sts The current value of the Product-Specific Logic Status being
received from the Host.
5 Prod Logic Sts The current value of the Product-Specific Status being received from
the Host.
6 Feedback The current value of the Product-Specific Feedback being received
from the Host.
7 Datalink A1 In The current value of Datalink A1 being transmitted to the Host.
(Value of 0 if Datalink is not used).
8 Datalink A2 In The current value of Datalink A2 being transmitted to the Host.
(Value of 0 if Datalink is not used).
9 Datalink B1 In The current value of Datalink B1 being transmitted to the Host.
(Value of 0 if Datalink is not used).
10 Datalink B2 In The current value of Datalink B2 being transmitted to the Host.
(Value of 0 if Datalink is not used).
11 Datalink C1 In The current value of Datalink C1 being transmitted to the Host.
(Value of 0 if Datalink not used).
12 Datalink C2 In The current value of Datalink C2 being transmitted to the Host.
(Value of 0 if Datalink is not used).
13 Datalink D1 In The current value of Datalink D1 being transmitted to the Host.
(Value of 0 if Datalink is not used).
14 Datalink D2 In The current value of Datalink D2 being transmitted to the Host.
(Value of 0 if Datalink is not used).
15 Datalink A1 Out The current value of Datalink A1 being received from the Host.
16 Datalink A2 Out The current value of Datalink A2 being received from the Host.
17 Datalink B1 Out The current value of Datalink B1 being received from the Host.
18 Datalink B2 Out The current value of Datalink B2 being received from the Host.
19 Datalink C1 Out The current value of Datalink C1 being received from the Host.
20 Datalink C2 Out The current value of Datalink C2 being received from the Host.
21 Datalink D1 Out The current value of Datalink D1 being received from the Host.
22 Datalink D2 Out The current value of Datalink D2 being received from the Host.
23 Field Flash Cntr The number of times this device has been flash updated.
24 DPI Rx Err Cntr The current value of the DPI CAN Receive error counter.
25 DPI Tx Err Cntr The current value of the DPI CAN Transmit error counter.
26 IbusImage Siz Amount of process data bytes used on the Interbus network by the
adapter.
