Chapter
3
Configuring the Serial Converter
Module
Chapter 3 provides instructions and information for configuring the
serial converter module.
For a list of parameters, refer to Appendix B , Serial Converter Module
Parameters . For definitions of terms in this chapter, refer to the Glossary .
The serial converter module stores parameters and other information in
its own non-volatile memory. You must, therefore, access the module to
view and edit its parameters. The following tools can be used to access
the module parameters.
Important: The RS-485 serial port on DSI products, such as PowerFlex
4 and 40 drives, does not need to be configured before using
the serial converter module. DSI communications are
configured automatically (19.2K baud and 8-N-1).
Topic Page
Configuration Tools 3-1
Using DriveExplorer 3-2
Using Terminal Emulation Software 3-3
Setting the RS-232 Serial Port Rate 3-7
Setting the Fault Action 3-8
Resetting the Serial Converter Module 3-9
Configuration Tools
Tool Refer To
DriveExplorer software (version 3.01 or higher) page 3-2 in this manual
DriveExecutive software (version 1.01 or higher)
KWWSZZZDEFRPGULYHV
GULYHWRROVB
Terminal emulation software page 3-3 in this manual
VT100-compatible terminal Documentation for the terminal
