Rockwell Automation 20L-LL PowerFlex 700L Liquid-to-Liquid Heat Exchanger User Manual
Page 36
B-2
Heat Exchanger Schematic
PowerFlex 700L Liquid-to-Liquid Heat Exchanger User Manual
-
+
COM
NO
COM (Red)
NC (Blue)
NO (Yellow)
6-
5+
12 VDC
13
14
11
12
9
10
7
8
GND
N
1L1
1
2
N
L1
GND
16 AWG Black
16 AWG Black
24 AWG White
24 AWG White
16 AWG Black
16 AWG Black
To PE Term Block
24 AWG White
24 AWG White
16 AWG Green
4 16 AWG White
3 16 AWG Black
16 AWG White
24 V
A
C
109T
120V
208V
240V
40VA
107CON
Orange
Yellow
Term Block
H4
Term Block
H2
Term Block
H1
Red
Black
White
Brown
109CON
12 AWG Green/Yellow
12 AWG White
12 AWG Black
GND
N
1L1
12 AWG Green/Yellow
12 AWG White
12 AWG Black
X1
16 AWG Red
16 AWG Red
H3
X2
111MV
Valve Motor
120 VAC
16A
(Maximum)
0.25A @120 VAC
30VA
(Maximum)
Flow Switch
113FLS
Level Switch
114FS
Ambient Temperature
115NTC
Water Temperature
116NTC
12 AWG Green/Yellow
12 AWG White
12 AWG Black
GND
12 AWG Green/Yellow
Field Installation
External
Power Connections
Voltage Primary
120 VAC H1, H2
230 VAC H1, H4
Transformer Input Wiring
AC POWER
To GND
Term Block
FRAME GND
PANEL GND
Term
Block
PE
Term
Block
L1
L1
T1
Term Block N
GND
NEUTRAL
HOT
Term Block
GND
