Installation 1-11
PowerFlex 700L Liquid-to-Liquid Heat Exchanger User Manual
Publication 20L-UM002A-EN-P
Figure 1.7 Control Board Component Locations
Figure 1.8 Motor Winding Connections for 230 VAC Operation
J2
J1
J3
S1
S2
J4
J8 J7 J6 J5
FU1
1
9
1 5
1 2 3 4 5 6 7 8 9 10
1 10 1 8
POWER Indicator
STATUS Indicator
NOTE: Terminal blocks J3, J4, J5, J6, J7, and J8 do
not require electrical connections by the user.
11
7 8 1
N O
6 5 4 3 2
1 = ON = Down
7 8 1
N O
6 5 4 3 2
S1
S2
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
115 VAC
Operation
Plug Position
230 VAC
Operation
Plug Position
MOTOR CONNECTIONS
115 VAC Operation
Blue L1 (Black)
N (White)
230 VAC Operation
Brown
Orange
Insulate
White
Yellow
Blue L1 (Black)
N (White)
Brown
Orange Insulate
Insulate
White
Yellow
