1-6 Installation
PowerFlex 700L Liquid-to-Liquid Heat Exchanger User Manual
Publication 20L-UM002A-EN-P
Connecting Hoses to the
Heat Exchanger Drive Loop (from Heat Exchanger to Drive)
Depending on the location of the heat exchanger relative to the drive, the
following drive cooling loop hose kits are available:
Alternately, the following parts can be obtained from an appropriate supplier
to fabricate specific length hoses which must not exceed 9.1 m (30 ft.).
• 1-inch inside diameter hose Parker Hannifin p/n 801-16
• 1-inch swivel hose fitting female JIC (Joint Industrial Council) 37°
Parker Hannifin p/n 30682-16-16B
• 3/4-inch inside diameter hose Parker Hannifin p/n 801-12
• 3/4-inch swivel hose fitting female JIC (Joint Industrial Council) 37°
Parker Hannifin p/n 30682-12-12B
• 1-inch elbow Parker Hannifin p/n 16 CTX-B
To attach a coupling to a hose, lubricate the inside of the hose end with a
small amount of liquid soap. Set the coupling down on a solid surface and
push the hose onto the coupling — in one firm push — until the hose end is
flush against the plastic bushing on the coupling. Stopping before the hose
is fully on may make it difficult to push the hose completely onto the
coupling.
Connect the two drive cooling loop hoses from the heat exchanger to the
drive. Mating hose connections for the drive loop are shown in
Figure 1.3
and Figure 1.4 . The mating process includes the following steps:
1. Assemble the mating version of the fitting (with swivel nut) to each drive
fluid fitting, and tighten to wrench resistance or 3.3 N-m (30 lb.-in.).
Table 1.C Drive Cooling Loop Hose Kits
Used With
Hose Kit
Catalog Number Hose
Length Hoses
in Kit Drive Side (1)
Coupling Size
(1) All drive side hose kit fittings are 37 degree flare.
Heat Exchanger Side
Coupling Size
Frame 2 and
13 kW heat exchanger 20L-GH10-B1 3 m
(10 ft.) 2 0.75 inch 0.75 inch
Frame 2 and
13 kW heat exchanger 20L-GH30-B1 9.1 m
(30 ft.) 2 0.75 inch 0.75 inch
Frame 3A and
13 kW heat exchanger 20L-GH10-A2 3 m
(10 ft.) 2 1 inch 1 inch with 90° elbow
Frame 3A and
13 kW heat exchanger 20L-GH30-A2 9.1 m
(30 ft.) 2 1 inch 1 inch with 90° elbow
Frame 3B and
24 kW heat exchanger 20L-GH10-A1 3 m
(10 ft.) 2 1 inch 1 inch
Frame 3B and
24 kW heat exchanger 20L-GH30-A1 9.1 m
(30 ft.) 2 1 inch 1 inch
!
ATTENTION: Risk of equipment damage exists. Hose fittings
must be brass or stainless steel. Use of plated steel fittings is
prohibited.
