1.76 2014 (BOOK SIZE) Arch 1
Vinyl Sliding Patio Doors
HORIZONTAL SECTION - SINGLE HORIZONTAL SECTION - DOUBLE
HORIZONTAL SECTION - TRIPLE MULLED
HORIZONTAL SECTION - TRIPLE CONTINUOUS
4-9/16”
5-3/4”
2”
Unit Width
Rough Opening
4-9/16”
1-9/32”
Clear Opening
2-1/2”
Rough Opening
Unit Width
3-3/4”
5-3/4”
4-9/16”
1-9/32”
Clear Opening
2-1/2”
Rough Opening
Unit Width
4-1/4” 2”
2”
4-9/16”
1-9/32”
Clear Opening
2-1/2”
Rough Opening
Unit Width
4-1/4”
