Full lite panel dimensions – Therma-Tru ARCH 1 Dimensional Data - Book Size User Manual
Page 41
Dimensional
Data
Arch 1
2014 (BOOK SIZE)
1.41
Full Lite Panel Dimensions
FIBER CLASSIC AND SMOOTH-STAR HORIZONTAL PANEL SECTION
CONTOUR
GBG GRILLE SECTION
FLAT BAR
GBG GRILLE SECTION
23/32"
7/32"
13/16”
3/16”
A
Frame Width
A
Daylight
Width
1-1/2”
Panel Width
STEEL HORIZONTAL PANEL SECTION
A
Frame Width
A
Daylight
Width
Panel Width
1-1/2”
SCROLL LITE FRAME
EXTERNAL GRILLE SECTION
1-1/8”
3/8”
Single
Double
Triple
2/4 6/6
28
76 11/16
5 1/32
4 5/32
6 17/32
17 31/32
65 31/32
14 31/32
62 31/32
6.53
13.06
19.63
2/6 6/6
30
76 11/16
4 1/16
4 5/32
6 21/32
21 29/32
65 29/32
18 29/32
62 29/32
8.25
16.50
24.78
2/8 6/6
32
76 11/16
5 1/16
4 5/32
6 21/32
21 29/32
65 29/32
18 29/32
62 29/32
8.25
16.50
24.78
2/10 6/6
34
76 11/16
5 1/16
4 5/32
6 21/32
23 7/8
65 7/8
20 15/16
62 15/16
9.16
18.28
27.44
3/0 6/6
36
76 11/16
6 1/16
4 5/32
6 21/32
23 7/8
65 7/8
20 15/16
62 15/16
9.16
18.28
27.44
2/4 6/8
28
79 1/4
5 1/32
4 5/32
9 3/32
17 31/32
65 31/32
14 31/32
62 31/32
6.53
13.06
19.63
2/6 6/8
30
79 1/4
4 1/16
4 5/32
9 7/32
21 29/32
65 29/32
18 29/32
62 29/32
8.25
16.50
24.78
2/8 6/8
32
79 1/4
5 1/16
4 5/32
9 7/32
21 29/32
65 29/32
18 29/32
62 29/32
8.25
16.50
24.78
2/10 6/8
34
79 1/4
5 1/16
4 5/32
9 7/32
23 7/8
65 7/8
20 15/16
62 15/16
9.16
18.28
27.44
3/0 6/8
36
79 1/4
6 1/16
4 5/32
9 7/32
23 7/8
65 7/8
20 15/16
62 15/16
9.16
18.28
27.44
Frame
Width
Frame
Height
Daylight
Width
Daylight
Height
Fiber Classic, Smooth-Star, and Steel with Scroll Lite Frame - Panel Size
Sq. Ft.
Daylight Opening
Door Panel Panel
Width
Panel
Height
A
B
C
