6/8 flush-glazed grille locations – Therma-Tru ARCH 1 Dimensional Data - Book Size User Manual
Page 68
Dimensional
Data
1.68
2014 (BOOK SIZE)
Arch 1
D
E
A
C
D
D
E
F
D
E
D
A
C
D
Panel
Glass
A
B
C
D
12
8 x 47
6"
-
9-5/8"
47-5/8"
14
8 x 47
7"
-
9-5/8"
47-5/8"
GBG - Flush-Glazed - Smooth-Star - 6'8" 3/4 Lite Sidelite - 6 Lite Prairie
Panel
Glass
A
B
C
D
12
8 x 47
-
-
-
28-5/8"
14
8 x 47
-
-
-
28-5/8"
GBG - Flush-Glazed - Smooth-Star - 6'8" 3/4 Lite Sidelite - 1W2H
Panel
Glass
A
B
C
D
E
12
8 x 47
-
-
-
20-13/16" 36-7/16"
14
8 x 47
-
-
-
20-13/16" 36-7/16"
GBG - Flush-Glazed - Smooth-Star - 6'8" 3/4 Lite Sidelite - 1W3H
Panel
Glass
A
B
C
D
E
F
12"
8 x 47
-
-
-
17-1/16" 28-5/8" 40-3/16"
14"
8 x 47
-
-
-
17-1/16" 28-5/8" 40-3/16"
Wood Grilles - Flush-Glazed - Fiber Classic - 6'8" 3/4 Lite Sidelite - 1W4H
Panel
Glass
A
B
C
D
E
F
12
8 x 47
-
-
-
16-7/8" 28-5/8" 40-5/16"
14
8 x 47
-
-
-
16-7/8" 28-5/8" 40-5/16"
GBG - Flush-Glazed - Smooth-Star - 6'8" 3/4 Lite Sidelite - 1W4H
Panel
Glass
A
B
C
D
12
8 x 36
6"
-
9-3/16" 36-5/8"
14
8 x 36
7"
-
9-3/16" 36-5/8"
GBG - Flush-Glazed - Fiber Classic - 6'8" Half Lite Sidelite - 6 Lite Prairie
Panel
Glass
A
B
C
D
E
12"
8 x 36
-
-
-
17"
28-13/16"
14"
8 x 36
-
-
-
17"
28-13/16"
Wood Grilles - Flush-Glazed - Fiber Classic - 6'8" Half Lite Sidelite - 1W3H
Panel
Glass
A
B
C
D
E
12
8 x 36
-
-
-
16-7/8" 28-15/16"
14
8 x 36
-
-
-
16-7/8" 28-15/16"
GBG/SDL - Flush-Glazed - Fiber Classic - 6'8" Half Lite Sidelite - 1W3H
All dimensions shown are to the center of the muntin.
6/8 Flush-Glazed Grille Locations
