Dimensional
Data
1.22 2014 (BOOK SIZE) Arch 1
Unit and Rough Opening Sizing
SL
Inswing
(Viewed from the exterior)
Hand Designations
L
R
Left Hand
Right Hand
SR LS RS
S Vented Sidelite
(hinged off jamb)
45 7/8" 47 7/8" 49 7/8" 51 7/8" 53 7/8"
44 1/8" 46 1/8" 48 1/8" 50 1/8" 52 1/8"
Unit Dimension 43 3/8" 45 3/8" 47 3/8" 49 3/8" 51 3/8"
80
3/
4"
80"
79
1/
2"
83
1/
4"
82
1/
2"
82"
99
1/
4"
98
1/
2"
98"
*Outswing not available.
Rough Opening
Brickmould Dim.
Single with Venting Sidelite - Wide Mullion
Single with 12" Venting Sidelite - Wide Mullion 6/6, 6/8, 8/0
