Dimensional
Data
Arch 1 2014 (BOOK SIZE) 1.73
Vinyl Sliding Patio Doors
Vinyl Sliding Patio Doors - Panel Size
VERTICAL PANEL SECTION
Scale: 3” = 1’
HORIZONTAL PANEL SECTION
Scale: 3” = 1’
GRILLE SECTION
Scale: 1:1
Vinyl Sliding Patio Doors
GRILLE SECTION
Scale: 1:1
2-3/8” 2-3/8”
Daylight
Width
Panel Width
2-3/8”
2-3/8”
Daylight
Height
Panel
Height
23/32”
5/16”
13/16” 3/16”
Unit
Panel
Width
Panel
Height
Daylight
Width
Daylight
Height
2/6 Replacement Ht. 30-1/4” 76-1/4” 25-1/2” 71-1/2”
3/0 Replacement Ht. 36-1/4” 76-1/4” 31-1/2” 71-1/2”
4/0 Replacement Ht. 48-1/4” 76-1/4” 43-1/2” 71-1/2”
Unit
Sq. Ft.
Daylight
Opening
Clear
Opening
Width
Clear
Opening
Height
Sq. Ft.
Clear
Opening
PVISF30R 15.64 --- --- ---
PVIS(LF/RF)26R 25.32 25" 76-1/8” 13.21
PVIS(LF/RF)30R 31.28 31" 76-1/8” 16.38
PVIS(LF/RF)40R 43.19 43" 76-1/8” 22.73
PVIS(FLF/FRF)30R 46.92 31" 76-1/8” 16.38
