Dimensional
Data
1.36 2014 (BOOK SIZE) Arch 1
Unit and Rough Opening Sizing
VERTICAL SECTION
OUTSWING
THERMAL BREAK
VERTICAL SECTION
OUTSWING
NO THERMAL BREAK
VERTICAL SECTION
OUTSWING
COASTAL
HORIZONTAL SECTION
OUTSWING - DOUBLE w/ASTRAGAL
(RA shown)
4-9/16” 4-9/16” 4-9/16”
Unit
Height
Unit
Height
Unit
Height
Rough
Opening
Rough
Opening
Rough
Opening
Brickmould
Dimension
Brickmould
Dimension
Brickmould
Dimension
Unit Width
Rough Opening
4-9/16”
Brickmould Dimension
