Dimensional
Data
Arch 1
2014 (BOOK SIZE)
1.65
6/8 Flush-Glazed Grille Locations
B
C
D
E
A
B
C
D
Panel
Glass
A
B
C
D
2/6
22 x 36
8-5/16" 21-11/16" 9-3/16" 36-5/8"
2/8
22 x 36
9-5/16" 22-11/16" 9-3/16" 36-5/8"
3/0
22 x 36 11-5/16" 24-11/16" 9-3/16" 36-5/8"
GBG - Flush-Glazed - Fiber Classic - 6'8" Half Lite - 9 Lite Prairie
Panel
Glass
A
B
C
D
E
2/6
22 x 36
-
11-3/8" 18-5/8"
17"
28-13/16"
2/8
22 x 36
-
12-3/8" 19-5/8"
17"
28-13/16"
3/0
22 x 36
-
14-3/8" 21-5/8"
17"
28-13/16"
Wood Grilles - Flush-Glazed - Fiber Classic - 6'8" Half Lite - 3W3H
All dimensions shown are to the center of the muntin.
Panel
Glass
A
B
C
D
2/6
22 x 36
8-5/16" 21-11/16" 8-15/16" 36-3/8"
2/8
22 x 36
9-5/16" 22-11/16" 8-15/16" 36-3/8"
3/0
22 x 36 11-5/16" 24-11/16" 8-15/16" 36-3/8"
GBG - Flush-Glazed - Smooth-Star - 6'8" Half Lite - 9 Lite Prairie
Panel
Glass
A
B
C
D
E
2/6
22 x 36
-
11-7/16" 18-9/16" 16-3/4" 28-9/16"
2/8
22 x 36
-
12-7/16" 19-9/16" 16-3/4" 28-9/16"
3/0
22 x 36
-
14-7/16" 21-9/16" 16-3/4" 28-9/16"
Wood Grilles - Flush-Glazed - Smooth-Star - 6'8" Half Lite - 3W3H
Panel
Glass
A
B
C
D
E
2/6
22 x 36
-
11-5/16" 18-11/16" 16-7/8" 28-15/16"
2/8
22 x 36
-
12-5/16" 19-11/16" 16-7/8" 28-15/16"
3/0
22 x 36
-
14-5/16" 21-11/16" 16-7/8" 28-15/16"
GBG/SDL - Flush-Glazed - Fiber Classic - 6'8" Half Lite - 3W3H
Panel
Glass
A
B
C
D
E
2/6
22 x 36
-
11-5/16" 18-11/16" 16-5/8" 28-3/4"
2/8
22 x 36
-
12-5/16" 19-11/16" 16-5/8" 28-3/4"
3/0
22 x 36
-
14-5/16" 21-11/16" 16-5/8" 28-3/4"
GBG/SDL - Flush-Glazed - Smooth-Star - 6'8" Half Lite - 3W3H
