Dimensional
Data
1.26 2014 (BOOK SIZE) Arch 1
Unit and Rough Opening Sizing
SLRS
Inswing
L
R
Left Hand
Right Hand
(Viewed from the exterior)
Hand Designations
A Astragal
S Sidelite
SLAS SARS
88 1/2" 92 1/2" 96 1/2" 100 1/2" 104 1/2"
86 3/4" 90 3/4" 94 3/4" 98 3/4" 102 3/4"
Unit Dimension 86" 90" 94" 98" 102"
80
3/
4"
80"
79
1/
2"
83
1/
4"
82
1/
2"
82"
99
1/
4"
98
1/
2"
98"
*Outswing not available.
French with 2-12" Venting Sidelites - Wide Mullion 6/6, 6/8, 8/0
Rough Opening
Brickmould Dim.
French with Venting Sidelites - Wide Mullion
