Dimensional
Data
1.64
2014 (BOOK SIZE)
Arch 1
6/8 Flush-Glazed Grille Locations
B
C
D
E
F
A
A
D
E
A
D
A
B
C
D
Panel
Glass
A
B
C
D
2/6
20 x 64 8-13/16" 21-3/16"
9"
48-3/16"
2/8
20 x 64 9-13/16" 22-3/16"
9"
48-3/16"
2/10
25 x 47 8-13/16" 25-3/16"
9"
48-3/16"
3/0
25 x 47 9-13/16" 26-3/16"
9"
48-3/16"
GBG - Flush-Glazed - Smooth-Star - 6'8" 3/4 Lite - 9 Lite Prairie
Panel
Glass
A
B
C
D
2/6
20 x 64
15"
-
-
28-5/8"
2/8
20 x 64
16"
-
-
28-5/8"
2/10
25 x 47
17"
-
-
28-5/8"
3/0
25 x 47
18"
-
-
28-5/8"
GBG - Flush-Glazed - Smooth-Star - 6'8" 3/4 Lite - 2W2H
Panel
Glass
A
B
C
D
E
2/6
20 x 64
15"
-
-
20-5/8" 36-5/8"
2/8
20 x 64
16"
-
-
20-5/8" 36-5/8"
2/10
25 x 47
17"
-
-
20-5/8" 36-5/8"
3/0
25 x 47
18"
-
-
20-5/8" 36-5/8"
GBG - Flush-Glazed - Smooth-Star - 6'8" 3/4 Lite - 2W3H
Panel
Glass
A
B
C
D
E
F
2/6
20 x 64
15"
12-13/16" 21-3/16" 16-5/8" 28-5/8" 40-5/8"
2/8
20 x 64
16"
13-13/16" 22-3/16" 16-5/8" 28-5/8" 40-5/8"
2/10
25 x 47
17"
12-13/16" 21-3/16" 16-9/16" 28-5/8" 40-5/8"
3/0
25 x 47
18"
13-13/16" 22-3/16" 16-9/16" 28-5/8" 40-5/8"
GBG/SDL - Flush-Glazed - Smooth-Star - 6'8" 3/4 Lite - 3W4H and 2W4H*
*SDL not available in 2W4H configuration.
All dimensions shown are to the center of the muntin.
