8/0 lip lite grille locations – Therma-Tru ARCH 1 Dimensional Data - Book Size User Manual
Page 60
Dimensional
Data
1.60
2014 (BOOK SIZE)
Arch 1
8/0 Lip Lite Grille Locations
D
E
F
G
H
D
E
F
G
D
E
F
D
E
D
A
C
D
Panel
Glass
A
B
C
D
12"
7 x 64
6"
-
10-5/8" 65-3/4"
14"
7 x 64
7"
-
10-5/8" 65-3/4"
GBG - Lip Lite - 8'0" 3/4 Lite Sidelite - 6 Lite Prairie
Panel
Glass
A
B
C
D
12"
7 x 64
-
-
-
38-3/16"
14"
7 x 64
-
-
-
38-3/16"
GBG - Lip Lite - 8'0" 3/4 Lite Sidelite - 1W2H
Panel
Glass
A
B
C
D
E
12"
7 x 64
-
-
-
27-1/2" 48-7/8"
14"
7 x 64
-
-
-
27-1/2" 48-7/8"
GBG - Lip Lite - 8'0" 3/4 Lite Sidelite - 1W3H
Panel
Glass
A
B
C
D
E
F
12"
7 x 64
-
-
-
22-3/16" 38-3/16" 54-3/16"
14"
7 x 64
-
-
-
22-3/16" 38-3/16" 54-3/16"
GBG - Lip Lite - 8'0" 3/4 Lite Sidelite - 1W4H
Panel
Glass
A
B
C
D
E
F
G
12"
7 x 64
-
-
-
19-1/16" 31-13/16" 44-9/16" 57-5/16"
14"
7 x 64
-
-
-
19-1/16" 31-13/16" 44-9/16" 57-5/16"
Fixed Grilles - Lip Lite - 8'0" 3/4 Lite Sidelite - 1W5H
Panel
Glass
A
B
C
D
E
F
G
12"
7 x 64
-
-
-
19-5/16" 31-7/8" 44-1/2" 57-1/16"
14"
7 x 64
-
-
-
19-5/16" 31-7/8" 44-1/2" 57-1/16"
Wood Grilles - Lip Lite - 8'0" 3/4 Lite Sidelite - 1W5H
Panel
Glass
A
B
C
D
E
F
G
12"
7 x 64
-
-
-
19"
31-13/16" 44-9/16" 57-3/8"
14"
7 x 64
-
-
-
19"
31-13/16" 44-9/16" 57-3/8"
GBG/SDL - Lip Lite - 8'0" 3/4 Lite Sidelite - 1W5H
Panel
Glass
A
B
C
D
E
F
G
H
12"
7 x 80
-
-
-
19-1/4" 32-13/16" 46-5/16" 59-13/16" 73-3/8"
14"
7 x 80
-
-
-
19-1/4" 32-13/16" 46-5/16" 59-13/16" 73-3/8"
Fixed Grilles - Lip Lite - 8'0" Full Lite Sidelite - 1W6H
Panel
Glass
A
B
C
D
E
F
G
H
12"
7 x 80
-
-
-
19-5/8"
33"
46-5/16" 59-5/8"
73"
14"
7 x 80
-
-
-
19-5/8"
33"
46-5/16" 59-5/8"
73"
GBG - Lip Lite - 8'0" Full Lite Sidelite - 1W6H
All dimensions shown are to the center of the muntin.
