Page 63
Dimensional
Data
Arch 1
2014 (BOOK SIZE)
1.63
6/8 Flush-Glazed Grille Locations
A
D
E
A
D
A
B
C
D
Panel
Glass
A
B
C
D
2/6
20 x 64
8-7/8"
21-1/8" 9-3/16" 64-5/8"
2/8
20 x 64
9-7/8"
22-1/8" 9-3/16" 64-5/8"
*2/10
25 x 64 8-13/16" 25-3/16" 9-3/16" 64-5/8"
3/0
27 x 64
8-7/8"
27-1/8" 9-3/16" 64-11/16"
GBG - Flush-Glazed - Fiber Classic - 6'8" Full Lite - 9 Lite Prairie
*Only available in 6/6
Panel
Glass
A
B
C
D
2/6
20 x 64
8-7/8"
21-1/8"
9"
64-7/16"
2/8
20 x 64
9-7/8"
22-1/8"
9"
64-7/16"
2/10
25 x 64 8-13/16" 25-3/16"
9"
64-7/16"
3/0
25 x 64 9-13/16" 26-3/16"
9"
64-7/16"
GBG - Flush-Glazed - Smooth-Star - 6'8" Full Lite - 9 Lite Prairie
Panel
Glass
A
B
C
D
2/6
20 x 64
15"
-
-
36-15/16"
2/8
20 x 64
16"
-
-
36-15/16"
*2/10
25 x 64
17"
-
-
36-15/16"
3/0
27 x 64
18"
-
-
36-15/16"
GBG - Flush-Glazed - Fiber Classic - 6'8" Full Lite - 2W2H
*Only available in 6/6
Panel
Glass
A
B
C
D
2/6
20 x 64
15"
-
-
36-3/4"
2/8
20 x 64
16"
-
-
36-3/4"
2/10
25 x 64
17"
-
-
36-3/4"
3/0
25 x 64
18"
-
-
36-3/4"
GBG - Flush-Glazed - Smooth-Star - 6'8" Full Lite - 2W2H
Panel
Glass
A
B
C
D
E
2/6
20 x 64
15"
-
-
26-3/16" 47-5/8"
2/8
20 x 64
16"
-
-
26-3/16" 47-5/8"
*2/10
25 x 64
17"
-
-
26-3/16" 47-5/8"
3/0
27 x 64
18"
-
-
26-3/16" 47-11/16"
GBG - Flush-Glazed - Fiber Classic - 6'8" Full Lite - 2W3H
*Only available in 6/6
Panel
Glass
A
B
C
D
E
2/6
20 x 64
15"
-
-
26"
47-7/16"
2/8
20 x 64
16"
-
-
26"
47-7/16"
2/10
25 x 64
17"
-
-
26"
47-7/16"
3/0
25 x 64
18"
-
-
26"
47-7/16"
GBG - Flush-Glazed - Smooth-Star - 6'8" Full Lite - 2W3H
All dimensions shown are to the center of the muntin.
