Arch 1
2014 (BOOK SIZE)
1.45
6/8 Lip Lite Grille Locations
C
D
F
G
B
E
A
A
B
C
D
E
F
A
D
E
Panel
Glass
A
B
C
D
E
2/4
16 x 64
14"
-
-
26-1/2" 47-7/8"
2/6
20 x 64
15"
-
-
26-7/16" 47-3/4"
2/8
22 x 64
16"
-
-
26-7/16" 47-3/4"
2/10
22 x 64
17"
-
-
26-7/16" 47-3/4"
3/0
22 x 64
18"
-
-
26-7/16" 47-3/4"
GBG - Lip Lite - 6'8" Full Lite - 2W3H
Panel
Glass
A
B
C
D
E
F
2/4
16 x 64
14"
11-5/16" 16-11/16" 21-3/16" 37-3/16" 53-3/16"
2/6
20 x 64
15"
11-11/16" 18-5/16" 21-1/8" 37-1/8" 53-1/8"
2/8
22 x 64
16"
12-5/16" 19-11/16" 21-1/8" 37-1/8" 53-1/8"
2/10
22 x 64
17"
13-5/16" 20-11/16" 21-1/8" 37-1/8" 53-1/8"
3/0
22 x 64
18"
14-5/16" 21-11/16" 21-1/8" 37-1/8" 53-1/8"
GBG - Lip Lite - 6'8" Full Lite - 3W4H and 2W4H
All dimensions shown are to the center of the muntin.
Panel
Glass
A
B
C
D
E
F
G
2/6
20 x 64
15"
11-11/16" 18-5/16" 17-15/16" 30-11/16" 43-1/2" 56-1/4"
2/8
22 x 64
16"
12-3/8" 19-5/8" 17-15/16" 30-11/16" 43-1/2" 56-1/4"
2/10
22 x 64
17"
13-3/8" 20-5/8" 17-15/16" 30-11/16" 43-1/2" 56-1/4"
3/0
22 x 64
18"
14-3/8" 21-5/8" 17-15/16" 30-11/16" 43-1/2" 56-1/4"
Fixed Grilles - Lip Lite - 6'8" Full Lite - 3W5H and 2W5H
Panel
Glass
A
B
C
D
E
F
G
2/6
20 x 64
15"
11-13/16" 18-3/16" 18-3/16" 30-13/16" 43-3/8"
56"
2/8
22 x 64
16"
12-1/2" 19-1/2" 18-3/16" 30-13/16" 43-3/8"
56"
2/10
22 x 64
17"
13-1/2" 20-1/2" 18-3/16" 30-13/16" 43-3/8"
56"
3/0
22 x 64
18"
14-1/2" 21-1/2" 18-3/16" 30-13/16" 43-3/8"
56"
Wood Grilles - Lip Lite - 6'8" Full Lite - 3W5H and 2W5H
Panel
Glass
A
B
C
D
E
F
G
*2/4
16 x 64
14"
11-5/16" 16-11/16" 17-7/8" 30-11/16" 43-1/2" 56-5/16"
2/6
20 x 64
15"
11-11/16" 18-5/16" 17-7/8" 30-11/16" 43-1/2" 56-5/16"
2/8
22 x 64
16"
12-5/16" 19-11/16" 17-7/8" 30-11/16" 43-1/2" 56-5/16"
2/10
22 x 64
17"
13-5/16" 20-11/16" 17-7/8" 30-11/16" 43-1/2" 56-5/16"
3/0
22 x 64
18"
14-5/16" 21-11/16" 17-7/8" 30-11/16" 43-1/2" 56-5/16"
*SDL not available.
GBG/SDL - Lip Lite - 6'8" Full Lite - 3W5H and 2W5H
