Unit and rough opening sizing – Therma-Tru ARCH 1 Dimensional Data - Book Size User Manual
Page 32
Dimensional
Data
1.32
2014 (BOOK SIZE)
Arch 1
Unit and Rough Opening Sizing
VERTICAL SECTION
INSWING - FIXED
VERTICAL SECTION
INSWING - SINGLE
VERTICAL SECTION
INSWING - DOUBLE w/ASTRAGAL
w/HINGED SCREEN
4-9/16”
Unit
Height
Rough
Opening
4-9/16”
Unit
Height
Rough
Opening
4-9/16”
Unit
Height
Rough
Opening
Brickmould
Dimension
Brickmould
Dimension
Brickmould
Dimension
