Dimensional
Data
1.34 2014 (BOOK SIZE) Arch 1
Unit and Rough Opening Sizing
HORIZONTAL SECTION
INSWING - SINGLE
(L shown)
HORIZONTAL SECTION
INSWING - DOUBLE w/MULLION
(LF shown)
HORIZONTAL SECTION
INSWING - DOUBLE w/ASTRAGAL
w/HINGED SCREEN
(AR shown)
HORIZONTAL SECTION
INSWING - SINGLE WITH VENTED SIDELITE
AND FIXED SCREEN
(LRR shown)
4-9/16”
Unit Width
Rough Opening
Brickmould Dimension
4-9/16”
Unit Width
Rough Opening
Brickmould Dimension
Unit Width
Rough Opening
4-9/16”
Brickmould Dimension
