Page 51
Dimensional
Data
Arch 1
2014 (BOOK SIZE)
1.51
6/8 Lip Lite Grille Locations
D
E
F
G
D
E
F
D
E
D
A
C
D
Panel
Glass
A
B
C
D
12"
7 x 64
6"
-
9-9/16" 64-11/16"
14"
7 x 64
7"
-
9-9/16" 64-11/16"
GBG - Lip Lite - 6'8" Full Lite Sidelite - 6 Lite Prairie
Panel
Glass
A
B
C
D
12"
7 x 64
-
-
-
37-1/8"
14"
7 x 64
-
-
-
37-1/8"
GBG - Lip Lite - 6'8" Full Lite Sidelite - 1W2H
Panel
Glass
A
B
C
D
E
12"
7 x 64
-
-
-
26-7/16" 47-13/16"
14"
7 x 64
-
-
-
26-7/16" 47-13/16"
GBG - Lip Lite - 6'8" Full Lite Sidelite - 1W3H
Panel
Glass
A
B
C
D
E
F
12"
7 x 64
-
-
-
21-1/8" 37-1/8" 53-1/8"
14"
7 x 64
-
-
-
21-1/8" 37-1/8" 53-1/8"
GBG - Lip Lite - 6'8" Full Lite Sidelite - 1W4H
Panel
Glass
A
B
C
D
E
F
G
12"
7 x 64
-
-
-
18"
30-3/4" 43-1/2" 56-1/4"
14"
7 x 64
-
-
-
18"
30-3/4" 43-1/2" 56-1/4"
Fixed Grilles - Lip Lite - 6'8" Full Lite Sidelite - 1W5H
Panel
Glass
A
B
C
D
E
F
G
12"
7 x 64
-
-
-
18-1/4" 30-13/16" 43-7/16"
56"
14"
7 x 64
-
-
-
18-1/4" 30-13/16" 43-7/16"
56"
Wood Grilles - Lip Lite - 6'8" Full Lite Sidelite - 1W5H
Panel
Glass
A
B
C
D
E
F
G
12"
7 x 64
-
-
-
17-15/16" 30-3/4" 43-1/2" 56-5/16"
14"
7 x 64
-
-
-
17-15/16" 30-3/4" 43-1/2" 56-5/16"
GBG/SDL - Lip Lite - 6'8" Full Lite Sidelite - 1W5H
All dimensions shown are to the center of the muntin.
